Merge branch 'develop' of https://labs.etsi.org/rep/tfs/controller into feat/device-perf-eval

hackfest/commands.txt

@@ -262,5 +262,43 @@ Service b8c99e2c-39d8-424d-9833-554634269555 deleted
 (mock-osm) exit
 Bye!

+############
+# gNMI
+############
+
+## Download and install the latest release
+$ sudo bash -c "$(curl -sL https://get.containerlab.dev)“
+
+## Deploy proposed two SR node scenario
+$ cd tfs-ctrl/hackfest/gnmi
+$ sudo containerlab deploy -t srlinux.clab.yml
+
+## Access SR Bash
+$ docker exec -it clab-srlinux-srl1 bash
+
+## Acess SR CLI
+$ docker exec -it clab-srlinux-srl1 sr_cli
+
+## Destroy scenario
+$ sudo containerlab destroy --topo srlinux.clab.yml
+
+## Install gNMIc
+$ sudo bash -c "$(curl -sL https://get-gnmic.kmrd.dev)"
+
+## gNMI Capabilities request
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify capabilities
+
+## gNMI Get request
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify -e json_ietf get --path /system/name/host-name
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify -e json_ietf get --path /interface[name=mgmt0]
+
+## gNMI Set request
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify -e json_ietf set --update-path /system/name/host-name --update-value slr11

+(we check the changed value)
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify -e json_ietf get --path /system/name/host-name

+## Subscribe request
+$ gnmic -a clab-srlinux-srl1 -u admin -p NokiaSrl1! --skip-verify -e json_ietf subscribe --path /interface[name=mgmt0]/statistics
+(In another terminal, you can generate traffic)
+$ssh admin@clab-srlinux-srl1

hackfest/gnmi/commands.txt

-== GNMI
-$ cd /usr/share/gocode/src/
-$ export GOPATH=/usr/share/gocode/
-$ go run github.com/openconfig/ygot/generator/generator.go -generate_fakeroot -output_file github.com/google/gnxi/gnmi/modeldata/gostruct/generated.go -package_name gostruct github.com/rvilalta/OFC_SC472/yang/topology.yang
-$ cd /usr/share/gocode/src/github.com/google/gnxi/gnmi_target
-$ go run gnmi_target.go -bind_address :10161 -config ~/tfs-ctrl/hackfest/gnmi/topology.json --notls -alsologtostderr
-
-RUN CLIENT (in another window)
-$ export GOPATH=/usr/share/gocode/
-$ cd /usr/share/gocode/src/github.com/google/gnxi/gnmi_get
-$ go run gnmi_get.go -notls -xpath "/topology/" -target_addr localhost:10161 -alsologtostderr
-$ go run gnmi_get.go -notls -xpath "/topology/node[node-id=A]" -target_addr localhost:10161 -alsologtostderr
-
-USE PYTHON CLIENT
-$ cd /usr/share/gocode/src/github.com/google/gnxi/gnmi_cli_py
-$ python py_gnmicli.py -n -m get -t localhost -p 10161 -x /topology -u foo -pass bar
-

hackfest/gnmi/sonic.clab.yml

+# file: sonic.clab.yml
+name: sonic-vs
+
+topology:
+  nodes:
+    srl1:
+      kind: sonic-vs
+      image: docker-sonic-vs
+    srl2:
+      kind: sonic-vs
+      image: docker-sonic-vs
+
+  links:
+    - endpoints: ["srl1:e1-1", "srl2:e1-1"]
+

hackfest/gnmi/topology.json

-{
-  "topology" : {
-     "node" : [
-       { "node-id" : "A" , "port" : [ { "port-id" : "portA1" } ] },
-       { "node-id" : "B" , "port" : [ { "port-id" : "portB1" } ] }
-     ]
-  }
-}
