charts/meep-app-enablement/values-template.yaml
View file @ 1e5ccfe0
......@@ -49,12 +49,19 @@ ingress:
- /{{.SandboxName}}/{{.MepName}}/service-apis
- /{{.SandboxName}}/{{.MepName}}/published-apis
- /{{.SandboxName}}/{{.MepName}}/capif-events
- /{{.SandboxName}}/{{.MepName}}/eecs-serviceprovisioning
- /{{.SandboxName}}/{{.MepName}}/eees-eecregistration
- /{{.SandboxName}}/{{.MepName}}/eees-easdiscovery
{{- else }}
- /{{.SandboxName}}/mec_app_support
- /{{.SandboxName}}/mec_service_mgmt
- /{{.SandboxName}}/service-apis
- /{{.SandboxName}}/published-apis
- /{{.SandboxName}}/capif-events
- /{{.SandboxName}}/eecs-serviceprovisioning
- /{{.SandboxName}}/eees-eecregistration
- /{{.SandboxName}}/eees-easdiscovery
{{- end }}
annotations:
kubernetes.io/ingress.class: nginx
......@@ -66,6 +73,9 @@ ingress:
rewrite ^/{{ .SandboxName }}/{{.MepName}}/service-apis(/|$)(.*)$ /service-apis/$2 break;
rewrite ^/{{ .SandboxName }}/{{.MepName}}/published-apis(/|$)(.*)$ /published-apis/$2 break;
rewrite ^/{{ .SandboxName }}/{{.MepName}}/capif-events(/|$)(.*)$ /capif-events/$2 break;
rewrite ^/{{ .SandboxName }}/{{.MepName}}/eecs-serviceprovisioning(/|$)(.*)$ /eecs-serviceprovisioning/$2 break;
rewrite ^/{{ .SandboxName }}/{{.MepName}}/eees-eecregistration(/|$)(.*)$ /eees-eecregistration/$2 break;
rewrite ^/{{ .SandboxName }}/{{.MepName}}/eees-easdiscovery(/|$)(.*)$ /eees-easdiscovery/$2 break;
{{- else }}
nginx.ingress.kubernetes.io/configuration-snippet: |
rewrite ^/{{ .SandboxName }}/mec_app_support(/|$)(.*)$ /mec_app_support/$2 break;
......@@ -73,6 +83,9 @@ ingress:
rewrite ^/{{ .SandboxName }}/service-apis(/|$)(.*)$ /service-apis/$2 break;
rewrite ^/{{ .SandboxName }}/published-apis(/|$)(.*)$ /published-apis/$2 break;
rewrite ^/{{ .SandboxName }}/capif-events(/|$)(.*)$ /capif-events/$2 break;
rewrite ^/{{ .SandboxName }}/eecs-serviceprovisioning(/|$)(.*)$ /eecs-serviceprovisioning/$2 break;
rewrite ^/{{ .SandboxName }}/eees-eecregistration(/|$)(.*)$ /eees-eecregistration/$2 break;
rewrite ^/{{ .SandboxName }}/eees-easdiscovery(/|$)(.*)$ /eees-easdiscovery/$2 break;
{{- end }}
{{- if .AuthEnabled }}
nginx.ingress.kubernetes.io/auth-url: https://$http_host/auth/v1/authenticate?svc=meep-app-enablement&sbox={{.SandboxName}}&mep={{.MepName}}
......
examples/demo6/python/notebook/MEC application.ipynb
View file @ 1e5ccfe0
%% Cell type:markdown id: tags:
# How to develop a MEC application using the MEC Sandbox HTTP REST API
This tutorial introduces the step by step procedure to create a basic MEC appcation following ETSI MEC standards.
This tutorial introduces the step by step procedure to create a basic MEC application following ETSI MEC standards.
It uses the ETSI MEC Sandbox simulator.
<div class="alert alert-block alert-danger">
<b>Note:</b> These source code examples are simplified and ignore return codes and error checks to a large extent. We do this to highlight how to use the MEC Sandbox API and the different MEC satndards and reduce unrelated code.
A real-world application will of course properly check every return value and exit correctly at the first serious error.
</div>
%% Cell type:markdown id: tags:
## What is a MEC application
See [The Wiki MEC web site](https://www.etsi.org/technologies/multi-access-edge-computing)
%% Cell type:markdown id: tags:
## The basics of developing a MEC application
The developement of a MEC application follows a strict process in order to access the ETSI MEC services and provides valuable services to the customers.
Mainly, this process can be split in several steps:
1. Global initializations (constant, variables...)
2. Create a new instance of a MEC Sandbox (Note that using an existing one could be a solution too (see Annex A))
3. Activate a network scenario in order to access the ETSI MEC services
4. Create a new application identifier
5. Register our MEC application and subscribe to service termination (see MEC 011)
6. Use MEC services in order to provide valuable services to the customers
6.1. Apply MEC services required subscriptions (e.g. MEC 013 location subscription)
7. Terminate the MEC application
7.1. Remove MEC services subscriptions
7.2. Deactivate the current network scenario
7.3. Delete the instance of the MEC Sandbox
8. Release all the MEC application resources
**Note:** Several application identifier can be created to address several MEC application.
## Use the MEC Sandbox HTTP REST API models and code
The MEC sandbox provides a piece of code (the python sub) that shall be used to develop the MEC application and interact with the MEC Sandbox. This piece of code mainly contains swagger models to serialize/deserialize JSON data structures and HTTP REST API call functions.
The openApi file is availabe [here](https://labs.etsi.org/rep/mec/etsi-mec-sandbox/-/blob/STF678_Task1_2_3_4/go-apps/meep-sandbox-api/api/swagger.yaml) and the [Swagger editor](https://editor-next.swagger.io/) is used to generate the python stub.
The project architecture is describe [here](images/project_arch.jpg).
The sandbox_api folder contains the python implementation of the HTTP REST API definitions introduced by the openApi [file](https://labs.etsi.org/rep/mec/etsi-mec-sandbox/-/blob/STF678_Task1_2_3_4/go-apps/meep-sandbox-api/api/swagger.yaml).
The model folder contains the python implementation of the data type definitions introduced by the openApi [file](https://labs.etsi.org/rep/mec/etsi-mec-sandbox/-/blob/STF678_Task1_2_3_4/go-apps/meep-sandbox-api/api/swagger.yaml).
<div class="alert alert-warning" role="alert">
<b>Note:</b> The sub-paragraph 'Putting everything together' is a specific paragraph where all the newly features introduced in the main paragraph are put together to create an executable block of code. It is possible to skip this block of code by removing the comment character (#) on first line of this block of code.
</div>
%% Cell type:markdown id: tags:
Before going to create our MEC application skeleton, the following steps shall be done:
1) Change the working directory (see the project architecture)
%% Cell type:code id: tags:
``` python
import os
os.chdir(os.path.join(os.getcwd(), '../mecapp'))
print(os.getcwd())
```
%% Cell type:markdown id: tags:
2) Apply the python imports
%% Cell type:code id: tags:
``` python
from __future__ import division # Import floating-point division (1/4=0.25) instead of Euclidian division (1/4=0)
import os
import sys
import re
import logging
import threading
import time
import json
import uuid
import pprint
import six
import swagger_client
from swagger_client.rest import ApiException
from http import HTTPStatus
from http.server import BaseHTTPRequestHandler, HTTPServer
try:
import urllib3
except ImportError:
raise ImportError('Swagger python client requires urllib3.')
```
%% Cell type:markdown id: tags:
3) Initialize of the global constants (cell 3)
%% Cell type:code id: tags:
``` python
MEC_SANDBOX_URL = 'https://mec-platform2.etsi.org' # MEC Sandbox host/base URL
MEC_SANDBOX_API_URL = 'https://mec-platform2.etsi.org/sandbox-api/v1' # MEC Sandbox API host/base URL
PROVIDER = 'Jupyter2024' # Login provider value - To skip authorization: 'github'
MEC_PLTF = 'mep1' # MEC plateform name. Linked to the network scenario
LOGGER_FORMAT = '%(asctime)s - %(name)s - %(levelname)s - %(message)s' # Logging format
STABLE_TIME_OUT = 10 # Timer to wait for MEC Sndbox reaches its stable state (K8S pods in running state)
LOGIN_TIMEOUT = 3 #30 # Timer to wait for user to authorize from GITHUB
LISTENER_IP = '0.0.0.0' # Listener IPv4 address for notification callback calls
LISTENER_PORT = 31111 # Listener IPv4 port for notification callback calls. Default: 36001
CALLBACK_URI = 'http://mec-platform2.etsi.org:31111/sandbox/v1'
#'https://yanngarcia.ddns.net:' + str(LISTENER_PORT) + '/jupyter/sandbox/demo6/v1/'
```
%% Cell type:markdown id: tags:
4) Setup the logger instance and the HTTP REST API (cell 4)
%% Cell type:code id: tags:
``` python
# Initialize the logger
logger = logging.getLogger(__name__)
logger.setLevel(logging.DEBUG)
logging.basicConfig(filename='/tmp/' + time.strftime('%Y%m%d-%H%M%S') + '.log')
l = logging.StreamHandler()
l.setFormatter(logging.Formatter('%(asctime)s - %(name)s - %(levelname)s - %(message)s'))
logger.addHandler(l)
# Setup the HTTP REST API configuration to be used to send request to MEC Sandbox API
configuration = swagger_client.Configuration()
configuration.host = MEC_SANDBOX_API_URL
configuration.verify_ssl = True
configuration.debug = True
configuration.logger_format = LOGGER_FORMAT
# Create an instance of ApiClient
sandbox_api = swagger_client.ApiClient(configuration, 'Content-Type', 'application/json')
# Setup the HTTP REST API configuration to be used to send request to MEC Services
configuration1 = swagger_client.Configuration()
configuration1.host = MEC_SANDBOX_URL
configuration1.verify_ssl = True
configuration1.debug = True
configuration1.logger_format = LOGGER_FORMAT
# Create an instance of ApiClient
service_api = swagger_client.ApiClient(configuration1, 'Content-Type', 'application/json')
```
%% Cell type:markdown id: tags:
5) Setup the global variables (cell 5)
%% Cell type:code id: tags:
``` python
# Initialize the global variables
nw_scenarios = [] # The list of available network scenarios
nw_scenario_idx = -1 # The network scenario idx to activate (deactivate)
app_inst_id = None # The requested application instance identifier
got_notification = False # Set to true if a POST notification is received
```
%% Cell type:markdown id: tags:
## Create our first MEC application
The first step to develop a MEC application is to create the application skeleton which contains the minimum steps below:
- Login to instanciate a MEC Sandbox
- Logout to delete a existing MEC Sandbox
%% Cell type:markdown id: tags:
### First steps: the login/logout
Here is the first squeleton with the following sequence:
- Login
- Print sandbox identifier
- Logout
- Check that logout is effective
%% Cell type:markdown id: tags:
#### The login function
To log to the MEC Sandbox,
the login process is done in two step. In step 1, a user code is requested to GITHUB. In step 2, the user has to enter this user code to https://github.com/login/device and proceed to the authorization.
Please, pay attention to the log '=======================> DO AUTHORIZATION WITH CODE :' which indicates you the user code to use for the authorization.
It uses the HTTP POST request with the URL 'POST /sandbox-sandbox_api/v1/login?provide=github' (see PROVIDER constant).
%% Cell type:code id: tags:
``` python
# Login
def process_login() -> str:
"""
Authenticate and create a new MEC Sandbox instance.
:return: The sandbox instance identifier on success, None otherwise
"""
global PROVIDER, logger
logger.debug('>>> process_login')
try:
auth = swagger_client.AuthorizationApi(sandbox_api)
oauth = auth.login(PROVIDER, async_req = False)
logger.debug('process_login (step1): oauth: ' + str(oauth))
# Wait for the MEC Sandbox is running
logger.debug('=======================> DO AUTHORIZATION WITH CODE : ' + oauth.user_code)
logger.debug('=======================> DO AUTHORIZATION HERE : ' + oauth.verification_uri)
if oauth.verification_uri == "":
time.sleep(LOGIN_TIMEOUT) # Skip scecurity, wait for a few seconds
else:
time.sleep(10 * LOGIN_TIMEOUT) # Wait for Authirization from user side
namespace = auth.get_namespace(oauth.user_code)
logger.debug('process_login (step2): result: ' + str(namespace))
return namespace.sandbox_name
except ApiException as e:
logger.error('Exception when calling AuthorizationApi->login: %s\n' % e)
return None
# End of function process_login
```
%% Cell type:markdown id: tags:
#### The logout function
It uses the HTTP POST request with the URL 'POST /sandbox-sandbox_api/v1/logout?sandbox_name={sandbox_name}'.
%% Cell type:code id: tags:
``` python
# Logout
def process_logout(sandbox_name: str) -> int:
"""
Delete the specified MEC Sandbox instance.
:param sandbox_name: The MEC Sandbox to delete
:return: 0 on success, -1 otherwise
"""
global logger
logger.debug('>>> process_logout: sandbox=' + sandbox_name)
try:
auth = swagger_client.AuthorizationApi(sandbox_api)
result = auth.logout(sandbox_name, async_req = False) # noqa: E501
return 0
except ApiException as e:
logger.error('Exception when calling AuthorizationApi->logout: %s\n' % e)
return -1
# End of function process_logout
```
%% Cell type:markdown id: tags:
Now, let put in action our Login/Logout functions:
%% Cell type:code id: tags:
``` python
#%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
%%script echo skipping
# Uncomment the line above to skip execution of this cell
def process_main():
"""
This is the skeleton of our MEC application:
- Login
- Print sandbox identifier
- Logout
- Check that logout is effective
This skeleton will be the bas of the next sprint in order to achieve a full implementation of a MEC application
"""
global logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Login
sandbox = process_login()
if sandbox is None:
return
# Print sandbox identifier
logger.info('Sandbox created: ' + sandbox)
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Logout
process_logout(sandbox)
# Check that logout is effective
logger.debug('To check that logout is effective, verify on the MEC Sandbox server that the MEC Sandbox is removed (kubectl get pods -A)')
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Second step: Retrieve the list of network scenarios
Let's go futhur and see how we can retrieve the list of the network scenarios available in order to activate one of them and access the MEC services exposed such as MEC 013 or MEC 030.
The sequence will be:
- Login
- Print sandbox identifier
- Print available network scenarios
- Logout
- Check that logout is effective
The login and logout functions are described in cell 3 and 4.
To retrieve the list of the network scenarios, let's create a new function called 'get_network_scenarios'. It uses the HTTP GET request with the URL '/sandbox-sandbox_api/v1/sandboxNetworkScenarios?sandbox_name={sandbox_name}'.
%% Cell type:code id: tags:
``` python
def get_network_scenarios(sandbox_name: str) -> list:
"""
Retrieve the list of the available network scenarios.
:param sandbox_name: The MEC Sandbox instance to use
:return: The list of the available network scenarios on success, None otherwise
"""
global PROVIDER, logger, sandbox_api, configuration
logger.debug('>>> get_network_scenarios: sandbox=' + sandbox_name)
try:
nw = swagger_client.SandboxNetworkScenariosApi(sandbox_api)
result = nw.sandbox_network_scenarios_get(sandbox_name, async_req = False) # noqa: E501
logger.debug('get_network_scenarios: result: ' + str(result))
return result
except ApiException as e:
logger.error('Exception when calling SandboxNetworkScenariosApi->sandbox_network_scenarios_get: %s\n' % e)
return None
# End of function get_network_scenarios
```
%% Cell type:markdown id: tags:
#### Putting everything together
Here the logic is:
- Login
- Print sandbox identifier
- Print available network scenarios
- Logout
- Check that logout is effective
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the first sprint of our skeleton of our MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Logout
- Check that logout is effective
"""
global logger, nw_scenarios
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Login
sandbox = process_login()
if sandbox is None:
logger.error('Failed to instanciate a MEC Sandbox')
return
# Print sandbox identifier
logger.info('Sandbox created: ' + sandbox)
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Print available network scenarios
nw_scenarios = get_network_scenarios(sandbox)
if nw_scenarios is None:
logger.error('Failed to retrieve the list of network scenarios')
elif len(nw_scenarios) != 0:
logger.info('nw_scenarios: %s', str(type(nw_scenarios[0])))
logger.info('nw_scenarios: %s', str(nw_scenarios))
else:
logger.info('nw_scenarios: No scenario available')
# Logout
process_logout(sandbox)
# Check that logout is effective
logger.debug('To check that logout is effective, verify on the MEC Sandbox server that the MEC Sandbox is removed (kubectl get pods -A)')
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Third step: Activate and deactivate a network scenario
Having a list of network scenarion, the next step is to actvate (and deactivate) a network scenario. This step is mandatory to create a new application instance id and access the MEC services.
In this section, we will arbitrary activate the network scenario called '4g-5g-macro-v2x', which is at the index 0 of the nw_scenarios.
%% Cell type:code id: tags:
``` python
def select_network_scenario_based_on_criteria(criterias_list: list) -> int:
"""
Select the network scenario to activate based of the provided list of criterias.
:param criterias_list: The list of criterias to select the correct network scenario
:return: 0 on success, -1 otherwise
"""
return 0 # The index of the '4g-5g-macro-v2x' network scenario - Hard coded
```
%% Cell type:markdown id: tags:
#### The activate function
The process to activate a scenario is based on an HTTP POST request with the URL '/sandboxNetworkScenarios/{sandbox_name}?network_scenario_id={network_scenario_id}'.
%% Cell type:code id: tags:
``` python
def activate_network_scenario(sandbox_name: str) -> int:
"""
Activate the specified network scenario.
:param sandbox_name: The MEC Sandbox instance to use
:return: 0 on success, -1 otherwise
"""
global logger, sandbox_api, nw_scenarios, nw_scenario_idx
logger.debug('>>> activate_network_scenario: ' + sandbox_name)
nw_scenario_idx = select_network_scenario_based_on_criteria([])
if nw_scenario_idx == -1:
logger.error('activate_network_scenario: Failed to select a network scenarion')
return -1
try:
nw = swagger_client.SandboxNetworkScenariosApi(sandbox_api)
nw.sandbox_network_scenario_post(sandbox_name, nw_scenarios[nw_scenario_idx].id, async_req = False) # noqa: E501
return 0
except ApiException as e:
logger.error('Exception when calling SandboxNetworkScenariosApi->activate_network_scenario: %s\n' % e)
return -1
# End of function activate_network_scenario
```
%% Cell type:markdown id: tags:
#### The deactivate function
The process to deactivate a scenario is based on an HTTP DELETE request with the URL '/sandboxNetworkScenarios/{sandbox_name}?network_scenario_id={network_scenario_id}'.
%% Cell type:code id: tags:
``` python
def deactivate_network_scenario(sandbox: str) -> int:
"""
Deactivate the current network scenario.
:param sandbox: The MEC Sandbox instance to use
:return: 0 on success, -1 otherwise
"""
global logger, sandbox_api, nw_scenarios, nw_scenario_idx
logger.debug('>>> deactivate_network_scenario: ' + sandbox)
try:
nw = swagger_client.SandboxNetworkScenariosApi(sandbox_api)
nw.sandbox_network_scenario_delete(sandbox, nw_scenarios[nw_scenario_idx].id, async_req = False) # noqa: E501
return 0
except ApiException as e:
logger.error('Exception when calling SandboxNetworkScenariosApi->deactivate_network_scenario: %s\n' % e)
return -1
# End of function deactivate_network_scenario
```
%% Cell type:markdown id: tags:
### Putting everything together
Now, it is time to create the second iteration of our MEC application.
The sequence is the following:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Check that the network scenario is activated and the MEC services are running
- Deactivate a network scenario
- Logout
- Check that logout is effective
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Check that the network scenario is activated and the MEC services are running
- Deactivate a network scenario
- Logout
- Check that logout is effective
"""
global logger, nw_scenarios, nw_scenario_idx
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Login
sandbox = process_login()
if sandbox is None:
logger.error('Failed to instanciate a MEC Sandbox')
return
# Print sandbox identifier
logger.info('Sandbox created: ' + sandbox)
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Print available network scenarios
nw_scenarios = get_network_scenarios(sandbox)
if nw_scenarios is None:
logger.error('Failed to retrieve the list of network scenarios')
elif len(nw_scenarios) != 0:
logger.info('nw_scenarios: %s', str(type(nw_scenarios[0])))
logger.info('nw_scenarios: %s', str(nw_scenarios))
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
else:
logger.info('nw_scenarios: No scenario available')
# Activate a network scenario based on a list of criterias (hard coded!!!)
if activate_network_scenario(sandbox) == -1:
logger.error('Failed to activate network scenario')
else:
logger.info('Network scenario activated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are running
time.sleep(2 * STABLE_TIME_OUT) # Wait for k8s pods up and running
# Check that the network scenario is activated and the MEC services are running
logger.info('To check that the network scenario is activated, verify on the MEC Sandbox server that the MEC services are running (kubectl get pods -A)')
time.sleep(30) # Sleep for 30 seconds
# Deactivate a network scenario based on a list of criterias (hard coded!!!)
if deactivate_network_scenario(sandbox) == -1:
logger.error('Failed to deactivate network scenario')
else:
logger.info('Network scenario deactivated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are terminated
time.sleep(2 * STABLE_TIME_OUT)
# Logout
process_logout(sandbox)
# Check that logout is effective
logger.debug('To check that logout is effective, verify on the MEC Sandbox server that the MEC Sandbox is removed (kubectl get pods -A)')
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Fourth step: Create and delete an appliction instance id
To enable our MEC application to be part of the activated network scenario, we need to request the MEC sandbox to create a new application instance identifier. Our MEC application will use this identifier to register to the MEC Sandbox according to MEC 011.
Reference: ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.2 MEC application start-up
#### The appliction instance id creation function
It is like the MEC application was instanciated by the MEC platform and it is executed locally.
%% Cell type:code id: tags:
``` python
def request_application_instance_id(sandbox_name: str) -> swagger_client.models.ApplicationInfo:
"""
Request the creation of a new MEC application instance identifier.
It is like the MEC application was instanciated by the MEC platform and it is executed locally.
:param sandbox_name: The MEC Sandbox instance to use
:return: The MEC application instance identifier on success, None otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.2 MEC application start-up
"""
global MEC_PLTF, logger, sandbox_api, configuration
logger.debug('>>> request_application_instance_id: ' + sandbox_name)
# Create a instance of our MEC application
try:
a = swagger_client.models.ApplicationInfo(id=str(uuid.uuid4()), name='JupyterMecApp', node_name=MEC_PLTF, type='USER') # noqa: E501
nw = swagger_client.SandboxAppInstancesApi(sandbox_api)
result = nw.sandbox_app_instances_post(a, sandbox_name, async_req = False) # noqa: E501
logger.debug('request_application_instance_id: result: ' + str(result))
return result
except ApiException as e:
logger.error('Exception when calling SandboxAppInstancesApi->sandbox_app_instances_post: %s\n' % e)
return None
# End of function request_application_instance_id
```
%% Cell type:markdown id: tags:
#### The appliction instance id deletion function
%% Cell type:code id: tags:
``` python
def delete_application_instance_id(sandbox_name: str, app_inst_id: str) -> int:
"""
Request the deletion of a MEC application.
:param sandbox: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:return: 0 on success, -1 otherwise
"""
global logger, sandbox_api, configuration
logger.debug('>>> delete_application_instance_id: ' + sandbox_name)
logger.debug('>>> delete_application_instance_id: ' + app_inst_id)
try:
nw = swagger_client.SandboxAppInstancesApi(sandbox_api)
nw.sandbox_app_instances_delete(sandbox_name, app_inst_id, async_req = False) # noqa: E501
return 0
except ApiException as e:
logger.error('Exception when calling SandboxAppInstancesApi->sandbox_app_instances_delete: %s\n' % e)
return -1
# End of function deletet_application_instance_id
```
%% Cell type:markdown id: tags:
#### Getting the list of applications
%% Cell type:code id: tags:
``` python
def get_applications_list(sandbox_name: str) -> list:
"""
Request the list of the MEC application available on the MEC Platform.
:param sandbox: The MEC Sandbox instance to use
:return: 0 on success, -1 otherwise
"""
global logger, sandbox_api, configuration
logger.debug('>>> get_applications_list: ' + sandbox_name)
try:
nw = swagger_client.SandboxAppInstancesApi(sandbox_api)
result = nw.sandbox_app_instances_get(sandbox_name, async_req = False) # noqa: E501
logger.debug('get_applications_list: result: ' + str(result))
return result
except ApiException as e:
logger.error('Exception when calling SandboxAppInstancesApi->get_applications_list: %s\n' % e)
return None
# End of function delete_application_instance_id
```
%% Cell type:markdown id: tags:
#### Putting everything together
It is time now to create the our third iteration of our MEC application.
The sequence is the following:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Retrieve the list of the applications instance identifier
- Check the demo application is present in the list of applications
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
- Check that logout is effective
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Retrieve the list of the applications instance identifier
- Check the demo application is present in the list of applications
- Deactivate a network scenario
- Logout
- Check that logout is effective
"""
global logger, nw_scenarios, nw_scenario_idx
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Login
sandbox = process_login()
if sandbox is None:
logger.error('Failed to instanciate a MEC Sandbox')
return
# Print sandbox identifier
logger.info('Sandbox created: ' + sandbox)
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Print available network scenarios
nw_scenarios = get_network_scenarios(sandbox)
if nw_scenarios is None:
logger.error('Failed to retrieve the list of network scenarios')
elif len(nw_scenarios) != 0:
logger.info('nw_scenarios: %s', str(type(nw_scenarios[0])))
logger.info('nw_scenarios: %s', str(nw_scenarios))
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
else:
logger.info('nw_scenarios: No scenario available')
# Activate a network scenario based on a list of criterias (hard coded!!!)
if activate_network_scenario(sandbox) == -1:
logger.error('Failed to activate network scenario')
else:
logger.info('Network scenario activated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are running
time.sleep(2 * STABLE_TIME_OUT) # Wait for k8s pods up and running
# Request for a new application instance identifier
app_inst_id = request_application_instance_id(sandbox)
if app_inst_id == None:
logger.error('Failed to request an application instance identifier')
else:
logger.info('app_inst_id: %s', str(type(app_inst_id)))
logger.info('app_inst_id: %s', str(app_inst_id))
# Check the demo application is present in the list of applications
app_list = get_applications_list(sandbox)
if app_list is None:
logger.error('Failed to request the list of applications')
else:
logger.info('app_list: %s', str(type(app_list)))
logger.info('app_list: %s', str(app_list))
# Check if our application is present in the list of applications
found = False
for item in app_list:
if item.id == app_inst_id.id:
found = True
break
if not found:
logger.error('Failed to retrieve our application instance identifier')
# Delete the application instance identifier
if delete_application_instance_id(sandbox, app_inst_id.id) == -1:
logger.error('Failed to delete the application instance identifier')
else:
logger.info('app_inst_id deleted: ' + app_inst_id.id)
# Deactivate a network scenario based on a list of criterias (hard coded!!!)
if deactivate_network_scenario(sandbox) == -1:
logger.error('Failed to deactivate network scenario')
else:
logger.info('Network scenario deactivated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are terminated
time.sleep(2 * STABLE_TIME_OUT)
# Logout
process_logout(sandbox)
# Check that logout is effective
logger.debug('To check that logout is effective, verify on the MEC Sandbox server that the MEC Sandbox is removed (kubectl get pods -A)')
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
## MEC Registration and the READY confirmation
Having an application instance identifier allows us to register with the MEC Sandbox and interact with it (e.g. to send service queries, to subscribe to events and to recieve notifications...).
The standard MEC 011 Clause 5.2.2 MEC application start-up describes the start up process. Basically, our MEC application has to:
1. Indicates that it is running by sending a Confirm Ready message
2. Retrieve the list of MEC services
To do so, a MEC application needs to be able to send requests but also to receive notifications (POST requests) and to reply to them.
%% Cell type:markdown id: tags:
### Fifth step: Send the READY confirmation
The MEC application instance confirms towards the MEC platform that it is up and running. It corresponds to step 4c described inETSI GS MEC 011 V3.2.1 (2024-04)11 Clause 5.2.2 MEC application start-up.
%% Cell type:code id: tags:
``` python
def send_ready_confirmation(sandbox_name: str, app_inst_id: swagger_client.models.application_info.ApplicationInfo) -> int:
"""
Send the ready_confirmation to indicate that the MEC application is active.
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:return: 0 on success, -1 otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.2 MEC application start-up - Step 4c
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> send_ready_confirmation: ' + app_inst_id.id)
try:
url = '/{sandbox_name}/{mec_pltf}/mec_app_support/v2/applications/{app_inst_id}/confirm_ready'
logger.debug('send_ready_confirmation: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['app_inst_id'] = app_inst_id.id
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# JSON indication READY
dict_body = {}
dict_body['indication'] = 'READY'
service_api.call_api(url, 'POST', header_params=header_params, path_params = path_params, body=dict_body, async_req=False)
return 0
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return -1
# End of function send_ready_confirmation
```
%% Cell type:markdown id: tags:
In addition, our MEC application is registering to AppTerminationNotificationSubscription and it needs to delete its subscription when terminating.
At this stage, it is important to note that all subscription deletion use the same format: <subscription URL>/<subscription identifier> (see ETSI MEC GS 003 [16]).
In this case, it the AppTerminationNotificationSubscription is 'sub-1234', the URIs to do the susbscription and to delete it are:
- MEC_SANDBOX_URL + '/' + sandbox_name + '/' + MEC_PLTF + '/mec_app_support/v2/applications/' + app_inst_id + '/subscriptions'
- MEC_SANDBOX_URL + '/' + sandbox_name + '/' + MEC_PLTF + '/mec_app_support/v2/applications/' + app_inst_id + '/subscriptions/sub-1234'
So, it will be usefull to create a small function to extract the subscription identifier from either the HTTP Location header or from the Link field found into the reponse body data structure.
%% Cell type:markdown id: tags:
#### Subscribing to application termination
The purpose is to create a new subscription to
the MEC application termination notification as describe in ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.6b Receiving event notifications on MEC application instance
terminations
%% Cell type:code id: tags:
``` python
def send_subscribe_termination(sandbox_name: str, app_inst_id: swagger_client.models.application_info.ApplicationInfo) -> object:
"""
Subscribe to the MEC application termination notifications.
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:return: The HTTP respone, the subscription ID and the resource URL on success, None otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.6b Receiving event notifications on MEC application instance termination
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> send_subscribe_termination: ' + app_inst_id.id)
try:
url = '/{sandbox_name}/{mec_pltf}/mec_app_support/v2/applications/{app_inst_id}/subscriptions'
logger.debug('send_subscribe_termination: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['app_inst_id'] = app_inst_id.id
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# Body
dict_body = {}
dict_body['subscriptionType'] = 'AppTerminationNotificationSubscription'
dict_body['callbackReference'] = CALLBACK_URI + '/mec011/v2/termination' # FIXME To be parameterized
dict_body['appInstanceId'] = app_inst_id.id
(result, status, headers) = service_api.call_api(url, 'POST', header_params=header_params, path_params = path_params, body=dict_body, async_req=False)
return (result, extract_sub_id(headers['Location']), headers['Location'])
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status, None)
# End of function send_subscribe_termination
```
%% Cell type:markdown id: tags:
#### Extracting subscription identifier
This helper function extracts the subscription identifier from any subscription URL.
%% Cell type:code id: tags:
``` python
def extract_sub_id(resource_url: str) -> str:
"""
Extract the subscription identifier from the specified subscription URL.
:param resource_url: The subscription URL
:return: The subscription identifier on success, None otherwise
"""
global logger
logger.debug('>>> extract_sub_id: resource_url: ' + resource_url)
res = urllib3.util.parse_url(resource_url)
if res is not None and res.path is not None and res.path != '':
id = res.path.rsplit('/', 1)[-1]
if id is not None:
return id
return None
# End of function extract_sub_id
```
%% Cell type:markdown id: tags:
#### Delete subscription to application termination
%% Cell type:code id: tags:
``` python
def delete_subscribe_termination(sandbox_name: str, app_inst_id: swagger_client.models.application_info.ApplicationInfo, sub_id: str) -> int:
"""
Delete the subscrition to the AppTermination notification.
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:param sub_id: The subscription identifier
:return: 0 on success, -1 otherwise
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> delete_subscribe_termination: ' + app_inst_id.id)
try:
url = '/{sandbox_name}/{mec_pltf}/mec_app_support/v2/applications/{app_inst_id}/subscriptions/{sub_id}'
logger.debug('delete_subscribe_termination: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['app_inst_id'] = app_inst_id.id
path_params['sub_id'] = sub_id
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
service_api.call_api(url, 'DELETE', header_params=header_params, path_params = path_params, async_req=False)
return 0
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return -1
# End of function delete_subscribe_termination
```
%% Cell type:markdown id: tags:
When the MEC application instance is notified to gracefully terminate, it provides to the MEC platform
that the application has completed its application level related terminate/stop actiono
Reference: ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.3 MEC application graceful termination/stopp.
%% Cell type:code id: tags:
``` python
def send_termination_confirmation(sandbox_name: str, app_inst_id: swagger_client.models.application_info.ApplicationInfo) -> int:
"""
Send the confirm_termination to indicate that the MEC application is terminating gracefully.
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:return: 0 on success, -1 otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.3 MEC application graceful termination/stop
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> send_termination_confirmation: ' + app_inst_id.id)
try:
url = '/{sandbox_name}/{mec_pltf}/mec_app_support/v2/applications/{app_inst_id}/confirm_termination'
logger.debug('send_termination_confirmation: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['app_inst_id'] = app_inst_id.id
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# JSON indication READY
dict_body = {}
dict_body['operationAction'] = 'TERMINATING'
service_api.call_api(url, 'POST', header_params=header_params, path_params = path_params, body=dict_body, async_req=False)
return 0
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return -1
# End of function send_termination_confirmation
```
%% Cell type:markdown id: tags:
#### Putting everythig together
Now, it is time now to create the our fifth iteration of our MEC application.
The sequence is the following:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Send READY confirmation
- Subscribe to AppTerminationNotificationSubscription
- Check list of services
- Delete AppTerminationNotification subscription
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
- Check that logout is effective
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Send READY confirmation
- Subscribe to AppTermination Notification
- Send Termination
- Delete AppTerminationNotification subscription
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
- Check that logout is effective
"""
global logger, nw_scenarios, nw_scenario_idx
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Login
sandbox = process_login()
if sandbox is None:
logger.error('Failed to instanciate a MEC Sandbox')
return
# Print sandbox identifier
logger.info('Sandbox created: ' + sandbox)
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Print available network scenarios
nw_scenarios = get_network_scenarios(sandbox)
if nw_scenarios is None:
logger.error('Failed to retrieve the list of network scenarios')
elif len(nw_scenarios) != 0:
logger.info('nw_scenarios: %s', str(type(nw_scenarios[0])))
logger.info('nw_scenarios: %s', str(nw_scenarios))
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
else:
logger.info('nw_scenarios: No scenario available')
# Activate a network scenario based on a list of criterias (hard coded!!!)
if activate_network_scenario(sandbox) == -1:
logger.error('Failed to activate network scenario')
else:
logger.info('Network scenario activated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are running
time.sleep(2 * STABLE_TIME_OUT) # Wait for k8s pods up and running
# Request for a new application instance identifier
app_inst_id = request_application_instance_id(sandbox)
if app_inst_id == None:
logger.error('Failed to request an application instance identifier')
else:
logger.info('app_inst_id: %s', str(app_inst_id))
time.sleep(STABLE_TIME_OUT)
# Send READY confirmation
sub_id = None
if send_ready_confirmation(sandbox, app_inst_id) == -1:
logger.error('Failed to send confirm_ready')
else:
# Subscribe to AppTerminationNotificationSubscription
result, sub_id, res_url = send_subscribe_termination(sandbox, app_inst_id)
if sub_id == None:
logger.error('Failed to do the subscription')
else:
logger.info('result: ' + str(result))
logger.info('sub_id: %s', sub_id)
data = json.loads(result.data)
logger.info('data: ' + str(data))
# Any processing here
time.sleep(STABLE_TIME_OUT)
# Delete AppTerminationNotification subscription
if sub_id is not None:
if delete_subscribe_termination(sandbox, app_inst_id, sub_id) == -1:
logger.error('Failed to delete the application instance identifier')
else:
logger.info('app_inst_id deleted: ' + app_inst_id.id)
# Delete the application instance identifier
if delete_application_instance_id(sandbox, app_inst_id.id) == -1:
logger.error('Failed to delete the application instance identifier')
else:
logger.info('app_inst_id deleted: ' + app_inst_id.id)
# Deactivate a network scenario based on a list of criterias (hard coded!!!)
if deactivate_network_scenario(sandbox) == -1:
logger.error('Failed to deactivate network scenario')
else:
logger.info('Network scenario deactivated: ' + nw_scenarios[nw_scenario_idx].id)
# Wait for the MEC services are terminated
time.sleep(2 * STABLE_TIME_OUT)
# Logout
process_logout(sandbox)
# Check that logout is effective
logger.debug('To check that logout is effective, verify on the MEC Sandbox server that the MEC Sandbox is removed (kubectl get pods -A)')
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Conclusion: Create two procedures for the setup and the termination of our MEC application
%% Cell type:markdown id: tags:
#### The procedure for the setup of a MEC application
This function provides the steps to setup a MEC application and to be ready to use the MEC service exposed by the created MEC Sandbox.
%% Cell type:code id: tags:
``` python
def mec_app_setup():
"""
This function provides the steps to setup a MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Send READY confirmation
- Subscribe to AppTermination Notification
:return The MEC Sandbox instance, the MEC application instance identifier and the subscription identifier on success, None otherwise
"""
global logger, nw_scenarios
# Login
sandbox = process_login()
if sandbox is None:
logger.error('Failed to instanciate a MEC Sandbox')
return None
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
# Print available network scenarios
nw_scenarios = get_network_scenarios(sandbox)
if nw_scenarios is None:
logger.error('Failed to retrieve the list of network scenarios')
elif len(nw_scenarios) != 0:
# Wait for the MEC Sandbox is running
time.sleep(STABLE_TIME_OUT) # Wait for k8s pods up and running
else:
logger.info('nw_scenarios: No scenario available')
# Activate a network scenario based on a list of criterias (hard coded!!!)
if activate_network_scenario(sandbox) == -1:
logger.error('Failed to activate network scenario')
else:
# Wait for the MEC services are running
time.sleep(2 * STABLE_TIME_OUT) # Wait for k8s pods up and running
# Request for a new application instance identifier
app_inst_id = request_application_instance_id(sandbox)
if app_inst_id == None:
logger.error('Failed to request an application instance identifier')
else:
# Wait for the MEC services are terminated
time.sleep(STABLE_TIME_OUT)
# Send READY confirmation
sub_id = None
if send_ready_confirmation(sandbox, app_inst_id) == -1:
logger.error('Failed to send confirm_ready')
else:
# Subscribe to AppTerminationNotificationSubscription
result, sub_id, res_url = send_subscribe_termination(sandbox, app_inst_id)
if sub_id == None:
logger.error('Failed to do the subscription')
return (sandbox, app_inst_id, sub_id)
# End of function mec_app_setup
```
%% Cell type:markdown id: tags:
#### The procedure for the termination of a MEC application
This function provides the steps to terminate a MEC application.
**Note:** All subscriptions done outside of the mec_app_setup function are not deleted.
%% Cell type:code id: tags:
``` python
def mec_app_termination(sandbox_name: str, app_inst_id:swagger_client.models.ApplicationInfo, sub_id: str):
"""
This function provides the steps to setup a MEC application:
- Login
- Print sandbox identifier
- Print available network scenarios
- Activate a network scenario
- Request for a new application instance identifier
- Send READY confirmation
- Subscribe to AppTermination Notification
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:param sub_id: The subscription identifier
"""
global logger
# Delete AppTerminationNotification subscription
if sub_id is not None:
if delete_subscribe_termination(sandbox_name, app_inst_id, sub_id) == -1:
logger.error('Failed to delete the application instance identifier')
# Delete the application instance identifier
if delete_application_instance_id(sandbox_name, app_inst_id.id) == -1:
logger.error('Failed to delete the application instance identifier')
else:
# Wait for the MEC services are terminated
time.sleep(STABLE_TIME_OUT)
# Deactivate a network scenario based on a list of criterias (hard coded!!!)
if deactivate_network_scenario(sandbox_name) == -1:
logger.error('Failed to deactivate network scenario')
else:
# Wait for the MEC services are terminated
time.sleep(2 * STABLE_TIME_OUT)
# Logout
process_logout(sandbox_name)
# End of function mec_app_termination
```
%% Cell type:markdown id: tags:
The following cell describes the new basic MEC application architecture. It will be used in the rest of this titorial.
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Mec application setup
- Get UU unicast provisioning information
- Mec application termination
"""
global logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Any processing here
logger.info('sandbox_name: ' + sandbox_name)
logger.info('app_inst_id: ' + app_inst_id.id)
if sub_id is not None:
logger.info('sub_id: ' + sub_id)
time.sleep(STABLE_TIME_OUT)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
## Create our second MEC application: how to use MEC Location Service
After doing the logging, network scenario activation, MEC application instance creation steps, we are ready to exploit the MEC services exposed by the MEC Sandbox.
In this clause, we use the following functionalities provided by MEC-013 LocationAPIs:
- Getting UE location lookup (ETSI GS MEC 013 Clause 5.3.2 UE Location Lookup)
- Subscribe to the UE Location changes (ETSI GS MEC 030 Clause 5.3.4)
- Delete subscription
### First step: Getting UE location lookup
First of all, just create a function to request the location of a specific UE. The UE identifier depends of the network scenario which was activated. In our example, we are using the 4g-5g-macro-v2x network scenario and we will run our code with the high velocity UE (i.e., the cars such as 10.100.0.1).
%% Cell type:code id: tags:
``` python
def get_ue_location(sandbox_name: str, ue: str) -> object:
"""
To retrieves the location information of an UE identified by its IPv4 address (e.g. 10.100.0.1)
:param sandbox_name: The MEC Sandbox instance to use
:return The HTTP response and the response status on success, None otherwise
:see ETSI GS MEC 013 V3.1.1 (2023-01) Clause 5.3.2 UE Location Lookup
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> get_ue_location: ' + ue)
try:
url = '/{sandbox_name}/{mec_pltf}/location/v3/queries/users'
logger.debug('get_ue_location: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
query_params = []
query_params.append(('address', ue))
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
(result, status, headers) = service_api.call_api(url, 'GET', header_params=header_params, path_params=path_params, query_params=query_params, async_req=False)
return (result, status)
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status)
# End of function get_ue_location
```
%% Cell type:markdown id: tags:
Let's create our new MEC application. The expected result looks like:
```json
{
"userList": {
"resourceURL": "https://mec-platform2.etsi.org/xxx/mep1/location/v3/queries/users",
"user": [
{
"address": "10.100.0.1",
"accessPointId": "4g-macro-cell-6",
"zoneId": "zone03",
"resourceURL": "https://mec-platform.etsi.org/xxx/mep1/location/v3/queries/users?address=10.100.0.1",
"timestamp": {
"nanoSeconds": 0,
"seconds": 1729245754
},
"locationInfo": {
"latitude": [
43.73707
],
"longitude": [
7.422555
],
"shape": 2
},
"civicInfo": {
"country": "MC"
},
"relativeLocationInfo": {
"X": 630.37036,
"Y": 261.92648,
"mapInfo": {
"mapId": "324561243",
"origin": {
"latitude": 43.7314,
"longitude": 7.4202
}
}
}
}
]
}
}
```
%% Cell type:markdown id: tags:
### Putting everything together
It is time now to create the our third iteration of our MEC application.
The sequence is the following:
- Login
- Activate a network scenario
- Getting UE location lookup (ETSI GS MEC 013 Clause 5.3.2)
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Login
- Activate a network scenario
- Getting UE location lookup (ETSI GS MEC 013 Clause 5.3.2)
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
"""
global logger, nw_scenarios
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Getting UE location lookup
result, status = get_ue_location(sandbox_name, '10.100.0.1')
logger.info('UE location information: status: %s', str(status))
if status != 200:
logger.error('Failed to get UE location information')
else:
logger.info('UE location information: %s', str(result.data))
# Any processing comes here
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('UserList: ' + str(data))
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Second step: Adding a subscription
The purpose here is to create a subscritpion when the UE (e.g. 10.100.0.1) is entering or leaving a PoA area (PoA is tanding for Piont of Access).
Accorcding to ETSI GS MEC 013 V3.1.1 Clause 7.5.3.4 POST, the 'request method is a POST and the endpoint is '/location/v3/subscriptions/users/'.
The cell below provides the code to create our subscription.
%% Cell type:markdown id: tags:
#### Notification support
To recieve notification, our MEC application is required to support an HTTP listenener to recieve POST requests from the MEC Sandbox and reply to them: this is the notification mechanism.
This minimalistic HTTP server will also be used to implement the endpoints provided by our MEC application service: see chapter [Our third MEC application: how to create a new MEC Services](#our_third_mec_application_how_to_create_a_new_mec_services).
The class HTTPRequestHandler (see cell below) provides the suport of such mechanism.
%% Cell type:code id: tags:
``` python
class HTTPServer_RequestHandler(BaseHTTPRequestHandler):
"""
Minimal implementation of an HTTP server (http only).
"""
def do_GET(self):
logger.info('>>> do_GET: ' + self.path)
ctype = self.headers.get('content-type')
logger.info('do_GET: ' + ctype)
message = ''
if self.path == '/statistic/v1/quantity':
if self.path == '/sandbox/v1/statistic/v1/quantity':
logger.info('do_GET: Computing statistic quantities for application MEC service')
# TODO Add logit to our MEC service
message = '{"time":20180124,"avg": 0.0,"max": 0.0,"min": 0.0,"stddev": 0.0 }'
else:
# Send message back to client
message = bytes(str(self.headers) + "\n" +self.requestline +"\n", 'utf8')
# Send error message
message = '{"title":"Unknown URI","type":"do_GET.parser","status":404 }'
logger.info('do_GET: message: ' + message)
# Send response status code
self.send_response(HTTPStatus.OK)
# Send headers
self.send_header('Content-type','text/plain; charset=utf-8')
self.send_header('Content-length', str(len(message)))
self.end_headers()
# Write content as utf-8 data
self.wfile.write(message)
self.wfile.write(message.encode('utf8'))
return
# End of function do_GET
def do_POST(self):
global got_notification
logger.info('>>> do_POST: ' + self.path)
ctype = self.headers.get('content-type')
logger.info('do_POST: ' + ctype)
content_len = int(self.headers.get('Content-Length'))
if content_len != 0:
body = self.rfile.read(content_len).decode('utf8')
logger.info('do_POST: body:' + str(type(body)))
logger.info('do_POST: body:' + str(body))
data = json.loads(str(body))
logger.info('do_POST: data: %s', str(data))
self.send_response(HTTPStatus.NOT_IMPLEMENTED)
self.end_headers()
got_notification = True
return
# End of function do_POST
def do_PUT(self):
logger.info('>>> do_PUT: ' + self.path)
ctype = self.headers.get('content-type')
logger.info('do_PUT: ' + ctype)
self.send_response(HTTPStatus.NOT_IMPLEMENTED)
self.end_headers()
return
# End of function do_PUT
def do_PATCH(self):
logger.info('>>> do_PATCH: ' + self.path)
ctype = self.headers.get('content-type')
logger.info('do_PATCH: ' + ctype)
self.send_response(HTTPStatus.NOT_IMPLEMENTED)
self.end_headers()
return
# End of function do_PATCH
# End of class HTTPRequestHandler
def do_DELETE(self):
logger.info('>>> do_DELETE: ' + self.path)
ctype = self.headers.get('content-type')
logger.info('do_DELETE: ' + ctype)
self.send_response(HTTPStatus.NOT_IMPLEMENTED)
self.end_headers()
return
# End of function do_DELETE
# End of class HTTPRequestHandler
def start_notification_server() -> HTTPServer:
"""
Start the notification server
:return The instance of the HTTP server
"""
global LISTENER_PORT, got_notification, logger
logger.debug('>>> start_notification_server on port ' + str(LISTENER_PORT))
got_notification = False
server_address = ('', LISTENER_PORT)
httpd = HTTPServer(server_address, HTTPServer_RequestHandler)
# Start notification server in a daemonized thread
notification_server = threading.Thread(target = httpd.serve_forever, name='notification_server')
notification_server.daemon = True
notification_server.start()
return httpd
# End of function HTTPRequestHandler
def stop_notification_server(httpd: HTTPServer):
"""
Stop the notification server
:param The instance of the HTTP server
"""
global logger
logger.debug('>>> stop_notification_server')
httpd.server_close()
httpd=None
# End of function HTTPRequestHandler
```
%% Cell type:code id: tags:
``` python
def subscribe_for_user_events(sandbox_name: str) -> object:
"""
Subscriptions for notifications related to location.
:param sandbox_name: The MEC Sandbox instance to use
:return: The HTTP respone, the subscription ID and the resource URL on success, None otherwise
:see ETSI GS MEC 013 V3.1.1 Clause 7.5 Resource: user_subscriptions
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> subscribe_for_user_events: ' + sandbox_name)
try:
url = '/{sandbox_name}/{mec_pltf}//location/v3/subscriptions/users'
logger.debug('subscribe_for_user_events: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# Body
dict_body = {}
dict_body['subscriptionType'] = 'UserLocationEventSubscription'
dict_body['callbackReference'] = CALLBACK_URI + '/mec013/v3/location' # FIXME To be parameterized
dict_body['address'] = '10.100.0.1' # FIXME To be parameterized
dict_body['clientCorrelator'] = "12345"
dict_body['locationEventCriteria'] = [ "ENTERING_AREA_EVENT", "LEAVING_AREA_EVENT"]
m = {}
m["userLocationEventSubscription"] = dict_body
(result, status, headers) = service_api.call_api(url, 'POST', header_params=header_params, path_params = path_params, body=m, async_req=False)
return (result, extract_sub_id(headers['Location']), headers['Location'])
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, None, None)
# End of function subscribe_for_user_are_event
```
%% Cell type:markdown id: tags:
### Putting everything together
It is time now to create the our third iteration of our MEC application.
The sequence is the following:
- Login
- Activate a network scenario
- Create subscription
- Wait for notification
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Login
- Activate a network scenario
- Create subscription
- Wait for notification
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
"""
global logger, nw_scenarios, got_notification
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Start notification server in a daemonized thread
httpd = start_notification_server()
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Create subscription
result, status, headers = subscribe_for_user_events(sandbox_name)
logger.info('UE location information: status: %s', str(status))
if status != 200:
logger.error('Failed to get UE location information')
else:
logger.info('UE location information: ' + str(result.data))
# Getting UE location lookup
result, status = get_ue_location(sandbox_name, '10.100.0.1')
logger.info('UE location information: status: ' + str(status))
if status != 200:
logger.error('Failed to get UE location information')
else:
logger.info('UE location information: ' + str(result.data))
# Wait for the notification
counter = 0
while not got_notification and counter < 30:
logger.info('Waiting for subscription...')
time.sleep(STABLE_TIME_OUT)
counter += 1
# End of 'while' statement
# Stop notification server
stop_notification_server(httpd)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
## Create our third MEC application: how to use V2X MEC Services
After doing the logging, network scenario activation, MEC application instance creation steps, we are ready to exploit the MEC services exposed by the MEC Sandbox.
In this clause, we use the following functionalities provided by MEC-030:
- Getting UU unicast provisioning information (ETSI GS MEC 030 Clause 5.5.1)
- Subscribe to the V2X message distribution server (ETSI GS MEC 030 Clause 5.5.7)
- Delete subscription
%% Cell type:markdown id: tags:
### Getting UU unicast provisioning information
The purpose is to query provisioning information for V2X communication over Uu unicast.
%% Cell type:code id: tags:
``` python
def send_uu_unicast_provisioning_info(sandbox_name: str, ecgi: str) -> object:
"""
Request for V2X communication over Uu unicast information
:param sandbox_name: The MEC Sandbox instance to use
:param ecgi: Comma separated list of locations to identify a cell of a base station or a particular geographical area
:return The Uu unicast provisioning information on success, None otherwise
:see ETSI GS MEC 030 V3.2.1 (2024-02) Clause 5.5.1 Sending a request for provisioning information for V2X communication over Uu unicast
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> send_uu_unicast_provisioning_info: ' + ecgi)
try:
url = '/{sandbox_name}/{mec_pltf}/vis/v2/queries/uu_unicast_provisioning_info'
logger.debug('send_uu_unicast_provisioning_info: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
query_params = []
query_params.append(('location_info', 'ecgi,' + ecgi))
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
(result, status, header) = service_api.call_api(url, 'GET', header_params=header_params, path_params=path_params, query_params=query_params, async_req=False)
return (result, status, header)
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status, None)
# End of function send_uu_unicast_provisioning_info
```
%% Cell type:markdown id: tags:
Let's create the our second MEC application.
The sequence is the following:
- Mec application setup
- Get UU unicast provisioning information
- Mec application termination
Note that the UU unicast provisioning information is returned as a JSON string. To de-serialized it into a Python data structure, please refer to clause [Subscribing to V2X message distribution server](#subscribing_to_v2x_message_distribution_server).
%% Cell type:markdown id: tags:
### Putting everything together
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Mec application setup
- Get UU unicast provisioning information
- Mec application termination
"""
global logger, nw_scenarios
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Get UU unicast provisioning information
ecgi = "268708941961,268711972264" # List of ecgi spearated by a ','
result, status, header = send_uu_unicast_provisioning_info(sandbox_name, ecgi)
logger.info('UU unicast provisioning information: status: %s', str(status))
if status != 200:
logger.error('Failed to get UU unicast provisioning information')
else:
logger.info('UU unicast provisioning information: %s', str(result.data))
# Any processing comes here
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('data: ' + str(data))
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Subscribing to V2X message distribution server
Here, we need to come back to the MEC 030 standard to create the type V2xMsgSubscription. It involves the creation of a set of basic types described below.
These new type shall be 'JSON' serializable. It means that they have to implement the following methods:
- to_dict()
- to_str()
- \_\_repr\_\_()
- \_\_eq\_\_()
- \_\_ne\_\_()
**Reference:** ETSI GS MEC 030 V3.2.1 (2024-02) Clause 6.5.13 Type: LinkType
%% Cell type:code id: tags:
``` python
class LinkType(object):
swagger_types = {'href': 'str'}
attribute_map = {'href': 'href'}
def __init__(self, href=None): # noqa: E501
self._href = None
if href is not None:
self._href = href
@property
def href(self):
return self._href
@href.setter
def href(self, href):
self._href = href
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(LinkType, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, LinkType):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class Links(object):
swagger_types = {'self': 'LinkType'}
attribute_map = {'self': 'self'}
def __init__(self, self_=None): # noqa: E501
self._self = None
if self_ is not None:
self._self = self_
@property
def self_(self):
return self._self
@self_.setter
def self_(self, self_):
self._self = self_
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Links, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Links):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class TimeStamp(object):
swagger_types = {'seconds': 'int', 'nano_seconds': 'int'}
attribute_map = {'seconds': 'seconds', 'nano_seconds': 'nanoSeconds'}
def __init__(self, seconds=None, nano_seconds=None): # noqa: E501
self._seconds = None
self._nano_seconds = None
if seconds is not None:
self._seconds = seconds
if nano_seconds is not None:
self._nano_seconds = nano_seconds
@property
def seconds(self):
return self._seconds
@seconds.setter
def seconds(self, seconds):
self._seconds = seconds
@property
def nano_seconds(self):
return self._nano_seconds
@nano_seconds.setter
def nano_seconds(self, nano_seconds):
self._nano_seconds = nano_seconds
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(TimeStamp, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, TimeStamp):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
```
%% Cell type:markdown id: tags:
The cell below implements the V2xMsgSubscription data structure."}
Reference: ETSI GS MEC 030 V3.2.1 (2024-02) Clause 6.3.5 Type: V2xMsgSubscription
%% Cell type:code id: tags:
``` python
class V2xMsgSubscription(object):
swagger_types = {'links': 'Links', 'callback_reference': 'str', 'filter_criteria': 'V2xMsgSubscriptionFilterCriteria', 'request_test_notification': 'bool', 'subscription_type': 'str'}
attribute_map = {'links': 'Links', 'callback_reference': 'callbackReference', 'filter_criteria': 'filterCriteria', 'request_test_notification': 'requestTestNotification', 'subscription_type': 'subscriptionType'}
def __init__(self, links=None, callback_reference=None, filter_criteria=None, request_test_notification=None): # noqa: E501
self._links = None
self._callback_reference = None
self._filter_criteria = None
self._request_test_notification = None
self._subscription_type = "V2xMsgSubscription"
if links is not None:
self.links = links
if callback_reference is not None:
self.callback_reference = callback_reference
if filter_criteria is not None:
self.filter_criteria = filter_criteria
if request_test_notification is not None:
self.request_test_notification = request_test_notification
@property
def links(self):
return self._links
@links.setter
def links(self, links):
self_.links = links
@property
def callback_reference(self):
return self._callback_reference
@callback_reference.setter
def callback_reference(self, callback_reference):
self._callback_reference = callback_reference
@property
def links(self):
return self._links
@links.setter
def links(self, links):
self._links = links
@property
def filter_criteria(self):
return self._filter_criteria
@filter_criteria.setter
def filter_criteria(self, filter_criteria):
self._filter_criteria = filter_criteria
@property
def request_test_notification(self):
return self._request_test_notification
@request_test_notification.setter
def request_test_notification(self, request_test_notification):
self._request_test_notification = request_test_notification
@property
def subscription_type(self):
return self._subscription_type
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(V2xMsgSubscription, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, V2xMsgSubscription):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class V2xMsgSubscriptionFilterCriteria(object):
swagger_types = {'msg_type': 'list[str]', 'std_organization': 'str'}
attribute_map = {'msg_type': 'MsgType', 'std_organization': 'stdOrganization'}
def __init__(self, msg_type, std_organization): # noqa: E501
self._msg_type = None
self._std_organization = None
self.msg_type = msg_type
self.std_organization = std_organization
@property
def msg_type(self):
return self._msg_type
@msg_type.setter
def msg_type(self, msg_type):
self._msg_type = msg_type
@property
def std_organization(self):
return self._std_organization
@std_organization.setter
def std_organization(self, std_organization):
self._std_organization = std_organization
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(V2xMsgSubscriptionFilterCriteria, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, V2xMsgSubscriptionFilterCriteria):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
```
%% Cell type:markdown id: tags:
Here is the V2X message subscription function. The HTTP Request message body contains a 'JSON' serialized instance of the class V2xMsgSubscription.
Reference: ETSI GS MEC 030 V3.2.1 (2024-02) Clause 5.5.10 V2X message interoperability
%% Cell type:code id: tags:
``` python
def subscribe_v2x_message(sandbox_name: str, v2xMsgSubscription: V2xMsgSubscription) -> object:
"""
Request to subscribe the V2X messages which come from different vehicle OEMs or operators
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:param sub_id: The subscription identifier
:return The HTTP response, the HTTP response status, the subscription identifier and the subscription URL on success, None otherwise
:see ETSI GS MEC 030 V3.2.1 (2024-02) Clause 5.5.10 V2X message interoperability
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> subscribe_v2x_message: v2xMsgSubscription: ' + str(v2xMsgSubscription))
try:
url = '/{sandbox_name}/{mec_pltf}/vis/v2/subscriptions'
logger.debug('subscribe_v2x_message: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
(result, status, headers) = service_api.call_api(url, 'POST', header_params=header_params, path_params=path_params, body=v2xMsgSubscription, async_req=False)
return (result, status, extract_sub_id(headers['Location']), headers['Location'])
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status, None)
# End of function subscribe_v2x_message
```
%% Cell type:markdown id: tags:
Here is a generic function to delete any MEC service subscription based on the subscription resource URL provided in the Location header of the subscription creation response.
%% Cell type:code id: tags:
``` python
def delete_mec_subscription(resource_url: str) -> int:
"""
Delete any existing MEC subscription
:param resource_url: The subscription URL
:return 0 on success, -1 otherwise
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> delete_mec_subscription: resource_url: ' + resource_url)
try:
res = urllib3.util.parse_url(resource_url)
if res is None:
logger.error('delete_mec_subscription: Failed to paerse URL')
return -1
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
service_api.call_api(res.path, 'DELETE', header_params=header_params, async_req=False)
return 0
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return -1
```
%% Cell type:markdown id: tags:
Finaly, here is how to implement the V2X message subscription:
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the second sprint of our skeleton of our MEC application:
- Mec application setup
- Subscribe to V2XMessage
- Delete subscription
- Mec application termination
"""
global MEC_PLTF, CALLBACK_URI, logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Create a V2X message subscritpion
filter_criteria = V2xMsgSubscriptionFilterCriteria(['1', '2'], 'ETSI')
v2xMsgSubscription = V2xMsgSubscription(callback_reference = CALLBACK_URI + '/vis/v2/v2x_msg_notification', filter_criteria = filter_criteria)
result, status, v2x_sub_id, v2x_resource = subscribe_v2x_message(sandbox_name, v2xMsgSubscription)
if status != 201:
logger.error('Failed to create subscription')
# Any processing here
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('data: %s', str(data))
logger.info('app_inst_id: ' + app_inst_id.id)
if sub_id is not None:
logger.info('sub_id: ' + sub_id)
time.sleep(STABLE_TIME_OUT)
# Delete the V2X message subscritpion
delete_mec_subscription(v2x_resource)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
### Putting everything together
let's add a subscription the our previous MEC application.
The sequence is the following:
- Mec application setup
- Start the notification server
- Get UU unicast provisioning information
- Add subscription
- Stop the notification server
- Mec application termination
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the third sprint of our skeleton of our MEC application:
- Mec application setup
- Start the notification server
- Get UU unicast provisioning information
- Add subscription
- Stop the notification server
- Mec application termination
"""
global CALLBACK_URI, logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
(sandbox_name, app_inst_id, sub_id) = mec_app_setup()
# Get UU unicast provisioning information
ecgi = "268708941961,268711972264" # List of ecgi spearated by a ','
result = send_uu_unicast_provisioning_info(sandbox_name, ecgi)
if result is None:
logger.error('Failed to get UU unicast provisioning information')
else:
logger.info('UU unicast provisioning information: ' + str(result))
# Start notification server in a daemonized thread
httpd = start_notification_server()
# Create a V2X message subscritpion
filter_criteria = V2xMsgSubscriptionFilterCriteria(['1', '2'], 'ETSI')
v2xMsgSubscription = V2xMsgSubscription(callback_reference = CALLBACK_URI + '/vis/v2/v2x_msg_notification', filter_criteria = filter_criteria)
result, status, v2x_sub_id, v2x_resource = subscribe_v2x_message(sandbox_name, v2xMsgSubscription)
if status != 201:
logger.error('Failed to create subscription')
# Any processing here
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('data: %s', str(data))
logger.info('v2x_resource: ' + v2x_resource)
if sub_id is not None:
logger.info('sub_id: ' + sub_id)
time.sleep(STABLE_TIME_OUT)
# Stop notification server
stop_notification_server(httpd)
# Delete the V2X message subscritpion
delete_mec_subscription(v2x_resource)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
## Create our fourth MEC application: how to use V2X QoS Prediction
The MEC Sanbox V2X QoS Prediction is based on a grid Map of Monaco City where areas are categorized into residential, commercial and coastal.
PoAs (Point Of Access) are categorized depending on where they lie in each grid.
Each category has its own traffic load patterns which are pre-determin. The V2X QoS Prediction) will give more accurate values of RSRP and RSRQ based on the diurnal traffic patterns for each. The network scenario named "4g-5g-v2x-macro" must be used to get access to the V2X QoS Prediction feature.
**Note:** The MEC Sanbox V2X QoS Prediction is enabled when the PredictedQos.routes.routeInfo.time attribute is present in the request (see ETSI GS MEC 030 V3.2.1 (2024-02) Clause 6.2.6 Type: Preditecd QoS)
Limitations:
* The Location Granularity is currently not being validated as RSRP/RSRP calculations are done at the exact location provided by the user.
* Time Granularity is currently not supported by the Prediction Function (design limitations of the minimal, emulated, pre-determined traffic prediction)
* Upper limit on the number of elements (10 each) in the routes and routeInfo structures (arrays) to not affect user experience and respoy
%% Cell type:markdown id: tags:
The table below describes the excepted Qos with and without the prediction model in deiffrent area and at different time.
| Location | Time | PoA | Category | Status | QoS without Prediction Model | QoS with Prediction Model | Expected |
| | (Unix time in sec) | Standard (GMT) | | | | RSRP | RSRQ | RSRP | RSRQ | |
| ------------------- | ----------- | -------------- | ---------------- | ----------- | ------------- | -------------- | ----------- | ----------- | ----------- | -------- |
| 43.729416,7.414853 | 1653295620 | 08:47:00 | 4g-macro-cell-2 | Residential | Congested | 63 | 21 | 60 | 20 | Yes |
| 43.732456,7.418417 | 1653299220 | 09:47:00 | 4g-macro-cell-3 | Residential | Not Congested | 55 | 13 | 55 | 13 | Yes |
| 43.73692,7.4209256 | 1653302820 | 10:47:00 | 4g-macro-cell-6 | Coastal | Not Congested | 68 | 26 | 68 | 26 | Yes |
| 43.738007,7.4230533 | 1653305220 | 11:27:00 | 4g-macro-cell-6 | Coastal | Not Congested | 55 | 13 | 55 | 13 | Yes |
| 43.739685,7.424881 | 1653308820 | 12:27:00 | 4g-macro-cell-7 | Commercial | Congested | 63 | 21 | 40 | 13 | Yes |
| 43.74103,7.425759 | 1653312600 | 13:30:00 | 4g-macro-cell-7 | Commercial | Congested | 56 | 14 | 40 | 8 | Yes |
| 43.74258,7.4277945 | 1653315900 | 14:25:00 | 4g-macro-cell-8 | Coastal | Congested | 59 | 17 | 47 | 13 | Yes |
| 43.744972,7.4295254 | 1653318900 | 15:15:00 | 4g-macro-cell-8 | Coastal | Congested | 53 | 11 | 40 | 5 | Yes |
| 43.74773,7.4320855 | 1653322500 | 16:15:00 | 5g-small-cell-14 | Commercial | Congested | 78 | 69 | 60 | 53 | Yes |
| 43.749264,7.435894 | 1653329700 | 18:15:00 | 5g-small-cell-20 | Commercial | Not Congested | 84 | 72 | 84 | 72 | Yes | 72 84 72 Yes
%% Cell type:markdown id: tags:
The image below illustrate the table above: [here](images/V2X Predicted QoS.jpg).
Here is an example of a basic V2X predicted QoS request based on two point in path at 8am in Residential area:
%% Cell type:markdown id: tags:
```json
{
"predictionTarget": "SINGLE_UE_PREDICTION",
"timeGranularity": null,
"locationGranularity": "30",
"routes": [
{
"routeInfo": [
{
"location": {
"geoArea": {
"latitude": 43.729416,
"longitude": 7.414853
}
},
"time": {
"nanoSeconds": 0,
"seconds": 1653295620
}
},
{
"location": {
"geoArea": {
"latitude": 43.732456,
"longitude": 7.418417
}
},
"time": {
"nanoSeconds": 0,
"seconds": 1653299220
]
}
]
}
%% Cell type:markdown id: tags:
Let first create the required types before to prepare a V2X Predicted QoS request based on the JSON above.
%% Cell type:code id: tags:
``` python
class Routes(object):
swagger_types = {'_route_info': 'list[RouteInfo]'}
attribute_map = {'_route_info': 'routeInfo'}
def __init__(self, route_info:list): # noqa: E501
self._route_info = None
self.route_info = route_info
@property
def route_info(self):
return self._route_info
@route_info.setter
def route_info(self, route_info):
if route_info is None:
raise ValueError("Invalid value for `route_info`, must not be `None`") # noqa: E501
self._route_info = route_info
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Routes, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Routes):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class LocationInfo(object):
swagger_types = {'_ecgi': 'Ecgi', '_geo_area': 'LocationInfoGeoArea'}
attribute_map = {'_ecgi': 'ecgi', '_geo_area': 'geoArea'}
def __init__(self, ecgi=None, geo_area=None): # noqa: E501
self._ecgi = None
self._geo_area = None
self.discriminator = None
if ecgi is not None:
self.ecgi = ecgi
if geo_area is not None:
self.geo_area = geo_area
@property
def ecgi(self):
return self._ecgi
@ecgi.setter
def ecgi(self, ecgi):
self._ecgi = ecgi
@property
def geo_area(self):
return self._geo_area
@geo_area.setter
def geo_area(self, geo_area):
self._geo_area = geo_area
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(LocationInfo, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, LocationInfo):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class RouteInfo(object):
swagger_types = {'_location': 'LocationInfo', '_time_stamp': 'TimeStamp'}
attribute_map = {'_location': 'location', '_time_stamp': 'time'}
def __init__(self, location:LocationInfo, time_stamp=None): # noqa: E501
self._location = None
self.location = location
self._time_stamp = None
if time_stamp is not None:
self.time_stamp = time_stamp
@property
def location(self):
return self._location
@location.setter
def location(self, location):
if location is None:
raise ValueError("Invalid value for `location`, must not be `None`") # noqa: E501
self._location = location
@property
def time_stamp(self):
return self._time_stamp
@time_stamp.setter
def time_stamp(self, time_stamp):
self._time_stamp = time_stamp
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(RouteInfo, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, RouteInfo):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class LocationInfoGeoArea(object):
swagger_types = {'_latitude': 'float', '_longitude': 'float'}
attribute_map = {'_latitude': 'latitude', '_longitude': 'longitude'}
def __init__(self, latitude, longitude): # noqa: E501
self._latitude = None
self._longitude = None
self.discriminator = None
if latitude is not None:
self.latitude = latitude
if longitude is not None:
self.longitude = longitude
@property
def latitude(self):
return self._latitude
@latitude.setter
def latitude(self, latitude):
if latitude is None:
raise ValueError("Invalid value for `latitude`, must not be `None`") # noqa: E501
self._latitude = latitude
@property
def longitude(self):
return self._longitude
@longitude.setter
def longitude(self, longitude):
if longitude is None:
raise ValueError("Invalid value for `longitude`, must not be `None`") # noqa: E501
self._longitude = longitude
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(LocationInfoGeoArea, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, LocationInfoGeoArea):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class Ecgi(object):
swagger_types = {'_cellId': 'CellId', '_plmn': 'Plmn'}
attribute_map = {'_cellId': 'cellId', '_plmn': 'plmn'}
def __init__(self, cellId=None, plmn=None): # noqa: E501
self._cellId = None
self._plmn = None
self.discriminator = None
if cellId is not None:
self.cellId = cellId
if plmn is not None:
self.plmn = plmn
@property
def cellId(self):
return self._cellId
@cellId.setter
def cellId(self, cellId):
self._cellId = cellId
@property
def plmn(self):
return self._plmn
@plmn.setter
def plmn(self, plmn):
self._plmn = plmn
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Ecgi, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Ecgi):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class CellId(object):
swagger_types = {'_cellId': 'str'}
attribute_map = {'_cellId': 'cellId'}
def __init__(self, cellId): # noqa: E501
self._cellId = None
self.cellId = cellId
@property
def cellId(self):
return self._cellId
@cellId.setter
def cellId(self, cellId):
if cellId is None:
raise ValueError("Invalid value for `cellId`, must not be `None`") # noqa: E501
self._cellId = cellId
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(CellId, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, CellId):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class Plmn(object):
swagger_types = {'_mcc': 'str', '_mnc': 'str'}
attribute_map = {'_mcc': 'mcc', '_mnc': 'mnc'}
def __init__(self, mcc:str, mnc:str): # noqa: E501
self.discriminator = None
self._mcc = None
self._mnc = None
self.mcc = mcc
self.mnc = mnc
@property
def mcc(self):
return self._mcc
@mcc.setter
def kpi_nmccame(self, mcc):
if mcc is None:
raise ValueError("Invalid value for `mcc`, must not be `None`") # noqa: E501
self._mcc = mcc
@property
def mnc(self):
return self._mnc
@mnc.setter
def kpi_nmccame(self, mnc):
if mnc is None:
raise ValueError("Invalid value for `mnc`, must not be `None`") # noqa: E501
self._mnc = mnc
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Plmn, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Plmn):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class QosKpi(object):
swagger_types = {'_kpi_name': 'str', '_kpi_value': 'str', '_confidence': 'str'}
attribute_map = {'_kpi_name': 'kpiName', '_kpi_value': 'kpiValue', '_confidence': 'Confidence'}
def __init__(self, kpi_name:str, kpi_value:str, confidence=None): # noqa: E501
self._kpi_name = None
self._kpi_value = None
self._confidence = None
self.kpi_name = kpi_name
self.kpi_value = kpi_value
if confidence is not None:
self.confidences = confidence
@property
def kpi_name(self):
return self._kpi_name
@kpi_name.setter
def kpi_name(self, kpi_name):
if kpi_name is None:
raise ValueError("Invalid value for `kpi_name`, must not be `None`") # noqa: E501
self._kpi_name = kpi_name
@property
def kpi_value(self):
return self._kpi_value
@kpi_value.setter
def kpi_value(self, kpi_value):
if kpi_value is None:
raise ValueError("Invalid value for `kpi_value`, must not be `None`") # noqa: E501
self._kpi_value = kpi_value
@property
def confidence(self):
return self._confidence
@confidence.setter
def confidence(self, confidence):
self._confidence = confidence
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(QosKpi, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, QosKpi):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class Stream(object):
swagger_types = {'_stream_id': 'str', '_qos_kpi': 'list[QosKpi]'}
attribute_map = {'_stream_id': 'streamId', '_qos_kpi': 'qosKpi'}
def __init__(self, stream_id:str, qos_kpi:list): # noqa: E501
self._stream_id = None
self._qos_kpi = None
self.stream_id = stream_id
self.qos_kpi = qos_kpi
@property
def stream_id(self):
return self._stream_id
@stream_id.setter
def stream_id(self, stream_id):
if stream_id is None:
raise ValueError("Invalid value for `stream_id`, must not be `None`") # noqa: E501
self._stream_id = stream_id
@property
def qos_kpi(self):
return self._qos_kpi
@qos_kpi.setter
def qos_kpi(self, qos_kpi):
if qos_kpi is None:
raise ValueError("Invalid value for `qos_kpi`, must not be `None`") # noqa: E501
self._qos_kpi = qos_kpi
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Stream, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Stream):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class Qos(object):
swagger_types = {'_stream': 'list[Stream]'}
attribute_map = {'_stream': 'stream'}
def __init__(self, stream:list): # noqa: E501
self._stream = None
self.stream = stream
@property
def stream(self):
return self._stream
@stream.setter
def stream(self, stream):
if stream is None:
raise ValueError("Invalid value for `stream`, must not be `None`") # noqa: E501
self._stream = stream
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(Qos, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, Qos):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class PredictedQos(object):
swagger_types = {'_location_granularity': 'str', '_notice_period': 'TimeStamp', '_prediction_area': 'PredictionArea', '_prediction_target': 'str', '_qos': 'Qos', '_routes': 'list[Routes]', '_time_granularity': 'TimeStamp'}
attribute_map = {'_location_granularity': 'locationGranularity', '_notice_period': 'noticePeriod', '_prediction_area': 'predictionArea', '_prediction_target': 'predictionTarget', '_qos': 'qos', '_routes': 'routes', '_time_granularity': 'timeGranularity'}
def __init__(self, prediction_target:str, location_granularity:str, notice_period=None, time_granularity=None, prediction_area=None, routes=None, qos=None): # noqa: E501
self._prediction_target = None
self._time_granularity = None
self._location_granularity = None
self._notice_period = None
self._prediction_area = None
self._routes = None
self._qos = None
self._prediction_target = prediction_target
if time_granularity is not None:
self.time_granularity = time_granularity
self.location_granularity = location_granularity
if notice_period is not None:
self.notice_period = notice_period
if prediction_area is not None:
self.prediction_area = prediction_area
if routes is not None:
self.routes = routes
if qos is not None:
self.qos = qos
@property
def prediction_target(self):
return self._prediction_target
@prediction_target.setter
def prediction_target(self, prediction_target):
if prediction_target is None:
raise ValueError("Invalid value for `prediction_target`, must not be `None`") # noqa: E501
self._prediction_target = prediction_target
@property
def time_granularity(self):
return self._time_granularity
@time_granularity.setter
def time_granularity(self, time_granularity):
self._time_granularity = time_granularity
@property
def location_granularity(self):
return self._location_granularity
@location_granularity.setter
def location_granularity(self, location_granularity):
if location_granularity is None:
raise ValueError("Invalid value for `location_granularity`, must not be `None`") # noqa: E501
self._location_granularity = location_granularity
@property
def notice_period(self):
return self._notice_period
@notice_period.setter
def notice_period(self, notice_period):
self._notice_period = notice_period
@property
def prediction_area(self):
return self._prediction_area
@prediction_area.setter
def prediction_area(self, prediction_area):
self._prediction_area = prediction_area
@property
def routes(self):
return self._routes
@routes.setter
def routes(self, routes):
self._routes = routes
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(PredictedQos, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, PredictedQos):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
```
%% Cell type:markdown id: tags:
Here is the V2X Prediscted QoS function.
Reference: ETSI GS MEC 030 V3.2.1 (2024-02) Clause 5.5.5 Sending a request for journey-specific QoS predictions
%% Cell type:code id: tags:
``` python
def get_qos_prediction(sandbox_name: str) -> object:
"""
Request to predictede QoS
:param sandbox_name: The MEC Sandbox instance to use
:return The HTTP response, the HTTP response status and the HTTP response headers on success, None otherwise
:see ETSI GS MEC 030 V3.2.1 (2024-02) Clause 5.5.5 Sending a request for journey-specific QoS predictions
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> get_qos_prediction: sandbox_name: ' + sandbox_name)
try:
url = '/{sandbox_name}/{mec_pltf}/vis/v2/provide_predicted_qos'
logger.debug('send_uu_unicast_provisioning_info: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
# HTTP header `Accept`
header_params = {}
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# Body request
loc1 = LocationInfo(geo_area=LocationInfoGeoArea(latitude=43.729416, longitude=7.414853))
loc2 = LocationInfo(geo_area=LocationInfoGeoArea(latitude=43.732456, longitude=7.418417))
routeInfo1 = RouteInfo(loc1, TimeStamp(nano_seconds=0, seconds=1653295620))
routeInfo2 = RouteInfo(loc2, TimeStamp(nano_seconds=0, seconds=1653299220))
routesInfo = [routeInfo1, routeInfo2]
predictedQos = PredictedQos(prediction_target="SINGLE_UE_PREDICTION", location_granularity="30", routes=[Routes(routesInfo)])
(result, status, headers) = service_api.call_api(url, 'POST', header_params=header_params, path_params=path_params, body=predictedQos, async_req=False)
return (result, status, headers)
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status, None)
# End of function send_uu_unicast_provisioning_info
```
%% Cell type:markdown id: tags:
Grouping all together provides the process_main funtion.. The sequence is the following:
- Mec application setup
- V2X QoS request
- Mec application termination
The expected response should be:
- RSRP: 55
- RSRQ: 13
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the fourth sprint of our skeleton of our MEC application:
- Mec application setup
- V2X QoS request
- Mec application termination
"""
global logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
sandbox_name, app_inst_id, sub_id = mec_app_setup()
# QoS Prediction
(result, status, headers) = get_qos_prediction(sandbox_name)
if status != 200:
logger.error('Failed to get UU unicast provisioning information')
else:
logger.info('UU unicast provisioning information: result: %s', str(result.data))
# Any processing here
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('data: %s', str(data))
time.sleep(STABLE_TIME_OUT)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
## Our fith MEC application: how to create a new MEC Services
The purpose of this MEC Service application is to provide a custom MEC service that can be use by other MEC applications. For the purpose of this tutorial, our MEC service is simulating some complex calculation based on a set of data provided by the MEC use.
We will use a second MEC application to exploit the features of our new MEC services.
In this clause, we use the following functionalities provided by MEC-011:
- Register a new service
- Retrieve the list of the MEC services exposed by the MEC platform
- Check that our new MEC service is present in the list of the MEC platform services
- Execute a request to the MEC service
- Delete the newly created service
**Note:** We will use a second MEC application to exploit the features of our new MEC services.
**Reference:** ETSI GS MEC 011 V3.2.1 (2024-04) Clause 5.2.4 Service availability update and new service registration
%% Cell type:markdown id: tags:
### Bases of the creation of a MEC service
#### Introduction
From the user perspective, a MEC service provides a set of endpoints which describe the interface of the MEC service (see [HTTP REST APIs
concepts](https://blog.postman.com/rest-api-examples/)). These endpoints come usually with a set of data structures used by the one or more endpoints.
Our service is really basic: it provide one endpoint:
- GET /statistic/v1/quantity: it computes statistical quantities of a set of data (such as average, max, min, standard deviation)
The body of this GET method is a list of datas:
```json
{"time":20180124,"data1":"[1516752000,11590.6,11616.9,11590.4,11616.9,0.25202387,1516752060,11622.4,11651.7,11622.4,11644.6,1.03977764]"}
```
The response body is the list of statistical quantities:
```json
{"time":20180124,"avg": 0.0,"max": 0.0,"min": 0.0,"stddev": 0.0 }
```
%% Cell type:markdown id: tags:
#### MEC mechanisms to create a new service
As described in ETSI GS MEC 011 Clause 5.2.4 Service availability update and new service registration, to create a new MEC service, the following information is required:
- A MEC Aplication instance: this is the MEC application providing the new MEC service (ETSI GS MEC 011 V3.2.1 Clause 8.2.6.3.4 POST)
- A ServiceInfo instance which describe the MEC service (ETSI GS MEC 011 V3.2.1 Clause 8.1.2.2 Type: ServiceInfo)
- As part of the ServiceInfo instance, a TransportInfo (ETSI GS MEC 011 V3.2.1 Clause 8.1.2.3 Type: TransportInfo) instance descibes the endpoints to use the MEC service
When created and available, all the other MEC applications are notified about the existance of this MEC service.
%% Cell type:markdown id: tags:
#### ServiceInfo data type
The cell below describes the ServiceInfo data structure and its dependencies. It will be used to create our MEC servie.
%% Cell type:code id: tags:
``` python
class ServiceInfo(object):
swagger_types = {'ser_instance_id': 'str','ser_name': 'str','ser_category': 'CategoryRef','version': 'str','state': 'str','transport_id': 'str','transport_info': 'TransportInfo','serializer': 'string','scope_of_locality': 'LocalityType','consumed_local_only': 'bool','is_local': 'bool','liveness_interval': 'int','links': 'ServiceInfoLinks'}
attribute_map = {'ser_instance_id': 'serInstanceId','ser_name': 'serName','ser_category': 'serCategory','version': 'version','state': 'state','transport_id': 'transportId','transport_info': 'transportInfo','serializer': 'serializer','scope_of_locality': 'scopeOfLocality','consumed_local_only': 'consumedLocalOnly','is_local': 'isLocal','liveness_interval': 'livenessInterval','links': '_links'}
def __init__(self, ser_instance_id=None, ser_name=None, ser_category=None, version=None, state=None, transport_id=None, transport_info=None, serializer=None, scope_of_locality=None, consumed_local_only=None, is_local=None, liveness_interval=None, links=None): # noqa: E501
self._ser_instance_id = None
self._ser_name = None
self._ser_category = None
self._version = None
self._state = None
self._transport_id = None
self._transport_info = None
self._serializer = None
self._scope_of_locality = None
self._consumed_local_only = None
self._is_local = None
self._liveness_interval = None
self._links = None
self.discriminator = None
if ser_instance_id is not None:
self.ser_instance_id = ser_instance_id
self.ser_name = ser_name
if ser_category is not None:
self.ser_category = ser_category
self.version = version
self.state = state
if transport_id is not None:
self.transport_id = transport_id
self.transport_info = transport_info
self.serializer = serializer
if scope_of_locality is not None:
self.scope_of_locality = scope_of_locality
if consumed_local_only is not None:
self.consumed_local_only = consumed_local_only
if is_local is not None:
self.is_local = is_local
if liveness_interval is not None:
self.liveness_interval = liveness_interval
if links is not None:
self.links = links
@property
def ser_instance_id(self):
return self._ser_instance_id
@ser_instance_id.setter
def ser_instance_id(self, ser_instance_id):
self._ser_instance_id = ser_instance_id
@property
def ser_name(self):
return self._ser_name
@ser_name.setter
def ser_name(self, ser_name):
if ser_name is None:
raise ValueError("Invalid value for `ser_name`, must not be `None`") # noqa: E501
self._ser_name = ser_name
@property
def ser_category(self):
return self._ser_category
@ser_category.setter
def ser_category(self, ser_category):
self._ser_category = ser_category
@property
def version(self):
return self._version
@version.setter
def version(self, version):
if version is None:
raise ValueError("Invalid value for `version`, must not be `None`") # noqa: E501
self._version = version
@property
def state(self):
return self._state
@state.setter
def state(self, state):
if state is None:
raise ValueError("Invalid value for `state`, must not be `None`") # noqa: E501
self._state = state
@property
def transport_id(self):
return self._transport_id
@transport_id.setter
def transport_id(self, transport_id):
self._transport_id = transport_id
@property
def transport_info(self):
return self._transport_info
@transport_info.setter
def transport_info(self, transport_info):
if transport_info is None:
raise ValueError("Invalid value for `transport_info`, must not be `None`") # noqa: E501
self._transport_info = transport_info
@property
def serializer(self):
return self._serializer
@serializer.setter
def serializer(self, serializer):
if serializer is None:
raise ValueError("Invalid value for `serializer`, must not be `None`") # noqa: E501
self._serializer = serializer
@property
def scope_of_locality(self):
return self._scope_of_locality
@scope_of_locality.setter
def scope_of_locality(self, scope_of_locality):
self._scope_of_locality = scope_of_locality
@property
def consumed_local_only(self):
return self._consumed_local_only
@consumed_local_only.setter
def consumed_local_only(self, consumed_local_only):
self._consumed_local_only = consumed_local_only
@property
def is_local(self):
return self._is_local
@is_local.setter
def is_local(self, is_local):
self._is_local = is_local
@property
def liveness_interval(self):
return self._liveness_interval
@liveness_interval.setter
def liveness_interval(self, liveness_interval):
self._liveness_interval = liveness_interval
@property
def links(self):
return self._links
@links.setter
def links(self, links):
self._links = links
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(ServiceInfo, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, ServiceInfo):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class CategoryRef(object):
swagger_types = {'href': 'str','id': 'str','name': 'str','version': 'str'}
attribute_map = {'href': 'href','id': 'id','name': 'name','version': 'version'}
def __init__(self, href=None, id=None, name=None, version=None): # noqa: E501
self._href = None
self._id = None
self._name = None
self._version = None
self.discriminator = None
self.href = href
self.id = id
self.name = name
self.version = version
@property
def href(self):
return self._href
@href.setter
def href(self, href):
if href is None:
raise ValueError("Invalid value for `href`, must not be `None`") # noqa: E501
self._href = href
@property
def id(self):
return self._id
@id.setter
def id(self, id):
if id is None:
raise ValueError("Invalid value for `id`, must not be `None`") # noqa: E501
self._id = id
@property
def name(self):
return self._name
@name.setter
def name(self, name):
if name is None:
raise ValueError("Invalid value for `name`, must not be `None`") # noqa: E501
self._name = name
@property
def version(self):
return self._version
@version.setter
def version(self, version):
if version is None:
raise ValueError("Invalid value for `version`, must not be `None`") # noqa: E501
self._version = version
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(CategoryRef, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, CategoryRef):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class TransportInfo(object):
swagger_types = {
'id': 'str','name': 'str','description': 'str','type': 'str','protocol': 'str','version': 'str','endpoint': 'OneOfTransportInfoEndpoint','security': 'SecurityInfo','impl_specific_info': 'str'}
attribute_map = {'id': 'id','name': 'name','description': 'description','type': 'type','protocol': 'protocol','version': 'version','endpoint': 'endpoint','security': 'security','impl_specific_info': 'implSpecificInfo'}
def __init__(self, id=None, name=None, description=None, type=None, protocol=None, version=None, endpoint=None, security=None, impl_specific_info=None): # noqa: E501
self._id = None
self._name = None
self._description = None
self._type = None
self._protocol = None
self._version = None
self._endpoint = None
self._security = None
self._impl_specific_info = None
self.discriminator = None
self.id = id
self.name = name
if description is not None:
self.description = description
self.type = type
self.protocol = protocol
self.version = version
self.endpoint = endpoint
self.security = security
if impl_specific_info is not None:
self.impl_specific_info = impl_specific_info
@property
def id(self):
return self._id
@id.setter
def id(self, id):
if id is None:
raise ValueError("Invalid value for `id`, must not be `None`") # noqa: E501
self._id = id
@property
def name(self):
return self._name
@name.setter
def name(self, name):
if name is None:
raise ValueError("Invalid value for `name`, must not be `None`") # noqa: E501
self._name = name
@property
def description(self):
return self._description
@description.setter
def description(self, description):
self._description = description
@property
def type(self):
return self._type
@type.setter
def type(self, type):
if type is None:
raise ValueError("Invalid value for `type`, must not be `None`") # noqa: E501
self._type = type
@property
def protocol(self):
return self._protocol
@protocol.setter
def protocol(self, protocol):
if protocol is None:
raise ValueError("Invalid value for `protocol`, must not be `None`") # noqa: E501
self._protocol = protocol
@property
def version(self):
return self._version
@version.setter
def version(self, version):
if version is None:
raise ValueError("Invalid value for `version`, must not be `None`") # noqa: E501
self._version = version
@property
def endpoint(self):
return self._endpoint
@endpoint.setter
def endpoint(self, endpoint):
if endpoint is None:
raise ValueError("Invalid value for `endpoint`, must not be `None`") # noqa: E501
self._endpoint = endpoint
@property
def security(self):
return self._security
@security.setter
def security(self, security):
if security is None:
raise ValueError("Invalid value for `security`, must not be `None`") # noqa: E501
self._security = security
@property
def impl_specific_info(self):
return self._impl_specific_info
@impl_specific_info.setter
def impl_specific_info(self, impl_specific_info):
self._impl_specific_info = impl_specific_info
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(TransportInfo, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, TransportInfo):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class SecurityInfo(object):
swagger_types = {'o_auth2_info': 'SecurityInfoOAuth2Info'}
attribute_map = {'o_auth2_info': 'oAuth2Info'}
def __init__(self, o_auth2_info=None): # noqa: E501
self._o_auth2_info = None
self.discriminator = None
if o_auth2_info is not None:
self.o_auth2_info = o_auth2_info
@property
def o_auth2_info(self):
return self._o_auth2_info
@o_auth2_info.setter
def o_auth2_info(self, o_auth2_info):
self._o_auth2_info = o_auth2_info
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(SecurityInfo, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, SecurityInfo):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class SecurityInfoOAuth2Info(object):
swagger_types = {'grant_types': 'list[str]','token_endpoint': 'str'}
attribute_map = {'grant_types': 'grantTypes','token_endpoint': 'tokenEndpoint'}
def __init__(self, grant_types=None, token_endpoint=None): # noqa: E501
self._grant_types = None
self._token_endpoint = None
self.discriminator = None
self.grant_types = grant_types
self.token_endpoint = token_endpoint
@property
def grant_types(self):
return self._grant_types
@grant_types.setter
def grant_types(self, grant_types):
if grant_types is None:
raise ValueError("Invalid value for `grant_types`, must not be `None`") # noqa: E501
self._grant_types = grant_types
@property
def token_endpoint(self):
return self._token_endpoint
@token_endpoint.setter
def token_endpoint(self, token_endpoint):
if token_endpoint is None:
raise ValueError("Invalid value for `token_endpoint`, must not be `None`") # noqa: E501
self._token_endpoint = token_endpoint
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(SecurityInfoOAuth2Info, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, SecurityInfoOAuth2Info):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class OneOfTransportInfoEndpoint(object):
swagger_types = {}
attribute_map = {}
def __init__(self): # noqa: E501
self.discriminator = None
@property
def uris(self):
return self._uris
@uris.setter
def uris(self, uris):
self._uris = uris
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(OneOfappInstanceIdServicesBody, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, OneOfTransportInfoEndpoint):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class EndPointInfoUris(object):
swagger_types = {'_uris': 'list[str]'}
attribute_map = {'_uris': 'uris'}
def __init__(self, uris:list): # noqa: E501
self._uris = None
self.uris = uris
@property
def uris(self):
return self._uris
@uris.setter
def uris(self, uris):
self._uris = uris
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(EndPointInfoUris, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, EndPointInfoUris):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class EndPointInfoFqdn(object):
swagger_types = {'_fqdn': 'list[str]'}
attribute_map = {'_fqdn': 'fqdn'}
def __init__(self, fqdn:list): # noqa: E501
self._fqdn = None
self.fqdn = fqdn
@property
def fqdn(self):
return self._fqdn
@fqdn.setter
def fqdn(self, fqdn):
self._fqdn = fqdn
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(EndPointInfoFqdn, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, EndPointInfoFqdn):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class EndPointInfoAddress(object):
swagger_types = {'_host': 'str', '_port': 'int'}
attribute_map = {'_host': 'host', '_port': 'port'}
def __init__(self, host:str, port:list): # noqa: E501
self._host = None
self._port = None
self.host = host
self.port = port
@property
def host(self):
return self.host
@host.setter
def host(self, host):
self._host = host
@property
def port(self):
return self._port
@port.setter
def port(self, port):
self._port = qosport_kpi
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,
value
))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(EndPointInfoAddress, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, EndPointInfoAddress):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class EndPointInfoAddresses(object):
swagger_types = {'_addresses': 'list[EndPointInfoAddress]'}
attribute_map = {'_addresses': 'addresses'}
def __init__(self, addresses:list): # noqa: E501
self._addresses = None
self.addresses = addresses
@property
def addresses(self):
return self._addresses
@addresses.setter
def addresses(self, addresses):
self._addresses = addresses
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(lambda x: x.to_dict() if hasattr(x, 'to_dict') else x,value))
elif hasattr(value, 'to_dict'):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], 'to_dict') else item,
value.items()
))
else:
result[attr] = value
if issubclass(EndPointInfoAddresses, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, EndPointInfoAddresses):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
class EndPointInfoAlternative(object):
swagger_types = {'alternative': 'object'}
attribute_map = {'alternative': 'alternative'}
def __init__(self, alternative=None): # noqa: E501
self._alternative = None
self.discriminator = None
self.alternative = alternative
@property
def alternative(self):
return self._alternative
@alternative.setter
def alternative(self, alternative):
if alternative is None:
raise ValueError("Invalid value for `alternative`, must not be `None`") # noqa: E501
self._alternative = alternative
def to_dict(self):
result = {}
for attr, _ in six.iteritems(self.swagger_types):
value = getattr(self, attr)
if isinstance(value, list):
result[attr] = list(map(
lambda x: x.to_dict() if hasattr(x, "to_dict") else x,
value
))
elif hasattr(value, "to_dict"):
result[attr] = value.to_dict()
elif isinstance(value, dict):
result[attr] = dict(map(
lambda item: (item[0], item[1].to_dict())
if hasattr(item[1], "to_dict") else item,
value.items()
))
else:
result[attr] = value
if issubclass(EndPointInfoAlternative, dict):
for key, value in self.items():
result[key] = value
return result
def to_str(self):
return pprint.pformat(self.to_dict())
def __repr__(self):
return self.to_str()
def __eq__(self, other):
if not isinstance(other, EndPointInfoAlternative):
return False
return self.__dict__ == other.__dict__
def __ne__(self, other):
return not self == other
```
%% Cell type:markdown id: tags:
### Create an application MEC service
The function below is creating an application MEC services
**Note:** This is call application MEC service in opposition of a standardized MEC service exposed by the MEC Sanbox such as MEC 013, MEC 030...
**Reference:** ETSI GS MEC 011 V3.2.1 (2024-04) Clause 8.2.6.3.4 POST
%% Cell type:code id: tags:
``` python
def create_mec_service(sandbox_name: str, app_inst_id: swagger_client.models.application_info.ApplicationInfo) -> object:
"""
Request to create a new application MEC service
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:param sub_id: The subscription identifier
:return The HTTP response, the response status and the headers on success, None otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 8.2.6.3.4 POST
"""
global MEC_PLTF, CALLBACK_URI, logger, service_api
logger.debug('>>> create_mec_service')
try:
url = '/{sandbox_name}/{mec_pltf}/mec_service_mgmt/v1/applications/{app_inst_id}/services'
logger.debug('create_mec_service: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['app_inst_id'] = app_inst_id.id
# HTTP header `Accept`
header_params = {}
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
# Body request
callback = CALLBACK_URI + '/statistic/v1/quantity'
transport_info = TransportInfo(id=str(uuid.uuid4()), name='HTTP REST API', type='REST_HTTP', protocol='HTTP', version='2.0', security=SecurityInfo(), endpoint=OneOfTransportInfoEndpoint())
transport_info.endpoint.uris=[EndPointInfoUris(callback)]
category_ref = CategoryRef(href=callback, id=str(uuid.uuid4()), name='Demo', version='1.0.0')
appServiceInfo = ServiceInfo(ser_name='demo6 MEC Service', ser_category=category_ref, version='1.0.0', state='ACTIVE',transport_info=transport_info, serializer='JSON')
(result, status, headers) = service_api.call_api(url, 'POST', header_params=header_params, path_params=path_params, body=appServiceInfo, async_req=False)
return (result, status, headers['Location'])
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status, None)
# End of function create_mec_service
```
%% Cell type:markdown id: tags:
### Delete an application MEC service
The function below is deleting an application MEC services.
**Reference:** ETSI GS MEC 011 V3.2.1 (2024-04) Clause 8.2.7.3.5 DELETE
%% Cell type:code id: tags:
``` python
def delete_mec_service(resource_url: str) -> int:
"""
Request to create a new application MEC service
:param sandbox_name: The MEC Sandbox instance to use
:param app_inst_id: The MEC application instance identifier
:param sub_id: The subscription identifier
:return 0 on success, -1 otherwise
:see ETSI GS MEC 011 V3.2.1 (2024-04) Clause 8.2.7.3.5 DELETE
"""
global logger
logger.debug('>>> delete_mec_subscription: resource_url: ' + resource_url)
try:
res = urllib3.util.parse_url(resource_url)
if res is None:
logger.error('delete_mec_subscription: Failed to paerse URL')
return -1
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
service_api.call_api(res.path, 'DELETE', header_params=header_params, async_req=False)
return 0
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return -1
# End of function delete_mec_service
```
%% Cell type:markdown id: tags:
### Putting everything together
The sequence is the following:
- Mec application setup
- Create new MEC service
- Send a request to our MEC service
- Delete newly created MEC service
- Mec application termination
%% Cell type:code id: tags:
``` python
#%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This is the fith sprint of our skeleton of our MEC application:
- Mec application setup
- Create new MEC service
- Send a request to our MEC service
- Delete newly created MEC service
- Mec application termination
"""
global LISTENER_IP, LISTENER_PORT, CALLBACK_URI, logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Start notification server in a daemonized thread
httpd = start_notification_server()
# Setup the MEC application
sandbox_name, app_inst_id, sub_id = mec_app_setup()
# Create the MEC service
result, status, mec_service_resource = create_mec_service(sandbox_name, app_inst_id)
if status != 201:
logger.error('Failed to create MEC service')
else:
logger.info('mec_service_resource: %s', mec_service_resource)
# Send a request to our MEC service
logger.info('body: ' + str(result.data))
data = json.loads(result.data)
logger.info('data: %s', str(data))
logger.info('=============> Execute the command: curl --request GET %s/statistic/v1/quantity --header "Accept: application/json" --data \'{"time":20180124,"data1":"[1516752000,11590.6,11616.9,11590.4,11616.9,0.25202387,1516752060,11622.4,11651.7,11622.4,11644.6,1.03977764]"}\'', CALLBACK_URI)
time.sleep(45)
time.sleep(60)
# Stop notification server
stop_notification_server(httpd)
# Delete the MEC servce
delete_mec_service(mec_service_resource)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
# Support of CAPIF (3GPP TS 29.222: 3rd Generation Partnership Project; Technical Specification Group Core Network and Terminals; Common API Framework for 3GPP Northbound APIs)
MEC-CAPIF support is described in ETSI GS MEC 011 (V3.2.1) Clause 9 [4]
The sample code below illustrates the usage of MEC-CAPI endpoints:
- /service-apis/v1/allServiceAPIs
- /published-apis/v1/{apfId}/service-apis
%% Cell type:markdown id: tags:
### Getting all MEC services
The code below illustrates how to use CAPIF '/service-apis/v1/allServiceAPIs' endpoint to retrieve the complete list of available MEC services.
**Reference:** ETSI GS MEC 011 (V3.2.1) Clause 9.2.3 Resource: All published service APIs
%% Cell type:code id: tags:
``` python
def capif_get_all_mec_services(sandbox_name: str):
"""
To retrieves the MEC services using CAPIF endpoint
:param sandbox_name: The MEC Sandbox instance to use
:return The HTTP response and the response status on success, None otherwise
:see ETSI GS MEC 011 (V3.2.1) Clause 9
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> capif_get_all_mec_services: ' + sandbox_name)
try:
url = '/{sandbox_name}/{mec_pltf}/service-apis/v1/allServiceAPIs'
logger.debug('capif_get_all_mec_services: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
(result, status, headers) = service_api.call_api(url, 'GET', header_params=header_params, path_params=path_params, async_req=False)
return (result, status)
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status)
# End of capif_get_all_mec_services function
```
%% Cell type:markdown id: tags:
### Getting MEC services for a specified MEC application instance ID
The code below illustrates how to use CAPIF '/published-apis/v1/{apfId}/service-apis' endpoint to retrieve the complete list of MEC services for a specified MEC application instance ID (apfid).
**Reference:** ETSI GS MEC 011 (V3.2.1) Table 9.2.4.2-1: Profiling of the URI variables
%% Cell type:markdown id: tags:
%% Cell type:code id: tags:
``` python
def capif_get_mec_services(sandbox_name: str, apfId: str):
"""
To retrieves the MEC services using CAPIF endpoint
:param sandbox_name: The MEC Sandbox instance to use
:param apfId: The identifier of the entity that registers the service API
:return The HTTP response and the response status on success, None otherwise
:see ETSI GS MEC 011 (V3.2.1) Clause 9
"""
global MEC_PLTF, logger, service_api
logger.debug('>>> capif_get_all_mec_services: ' + sandbox_name)
try:
url = '/{sandbox_name}/{mec_pltf}/published-apis/v1/{apfId}/service-apis'
logger.debug('capif_get_mec_services: url: ' + url)
path_params = {}
path_params['sandbox_name'] = sandbox_name
path_params['mec_pltf'] = MEC_PLTF
path_params['apfId'] = apfId
header_params = {}
# HTTP header `Accept`
header_params['Accept'] = 'application/json' # noqa: E501
# HTTP header `Content-Type`
header_params['Content-Type'] = 'application/json' # noqa: E501
(result, status, headers) = service_api.call_api(url, 'GET', header_params=header_params, path_params=path_params, async_req=False)
return (result, status)
except ApiException as e:
logger.error('Exception when calling call_api: %s\n' % e)
return (None, status)
# End of capif_get_mec_services function
```
%% Cell type:markdown id: tags:
### Putting evrythong together
It is time now to create the our third iteration of our MEC application.
The sequence is the following:
- Login
- Activate a network scenario
- Create an application instance identifier
- Retrieve all MEC services (/service-apis/v1/allServiceAPIs)
- Retrieve MEC services for the newly created application instance identifier
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
%% Cell type:code id: tags:
``` python
#%%script echo skipping
%%script echo skipping
# Uncomment the ;line above to skip execution of this cell
def process_main():
"""
This code illustrates the usage of MEC-CAPI endpoints:
- Login
- Activate a network scenario
- Create an application instance identifier
- Retrieve all MEC services (/service-apis/v1/allServiceAPIs)
- Retrieve MEC services for the newly created application instance identifier
- Delete our application instance identifier
- Deactivate a network scenario
- Logout
"""
global LISTENER_IP, LISTENER_PORT, CALLBACK_URI, logger
logger.debug('Starting at ' + time.strftime('%Y%m%d-%H%M%S'))
logger.debug('\t pwd= ' + os.getcwd())
# Setup the MEC application
sandbox_name, app_inst_id, sub_id = mec_app_setup()
# Get the list of the MEC sevices using CAPIF endpoints
result, status = capif_get_all_mec_services(sandbox_name)
if status != 200:
logger.error('Failed to get the list of MEC services using CAPIF endpoint')
else:
logger.info('capif_get_all_mec_services: ' + str(result.data))
# Get the list of the MEC sevices for our AppInstanceId using CAPIF endpoints
result, status = capif_get_mec_services(sandbox_name, app_inst_id.id)
if status != 200:
logger.error('Failed to get the list of MEC services for our AppInstanceId using CAPIF endpoint')
else:
logger.info('capif_get_mec_services: ' + str(result.data))
# In the previous request, the list of services for our AppInstanceId is empty.
# Let's create a new MEC service
result, status, mec_service_resource = create_mec_service(sandbox_name, app_inst_id)
if status != 201:
logger.error('Failed to create MEC service')
else:
logger.info('mec_service_resource: %s', mec_service_resource)
# Now, we can send a new request for services for our MEC application
# Get the list of the MEC sevices for our AppInstanceId using CAPIF endpoints
result, status = capif_get_mec_services(sandbox_name, app_inst_id.id)
if status != 200:
logger.error('Failed to get the list of MEC services for our AppInstanceId using CAPIF endpoint')
else:
logger.info('capif_get_mec_services: ' + str(result.data))
data = json.loads(result.data)
logger.info('serviceAPIDescriptions: ' + str(data))
# b'{"serviceAPIDescriptions":[{"apiName":"demo6 MEC Service","apiId":"6172de7d-ed42-4ba2-947a-a0db7cc8915e","aefProfiles":[{"aefId":"3daa9b79-ba81-4a74-9668-df710dc68020","versions":["1.0.0"],"interfaceDescriptions":{"uris":null,"fqdn":null,"addresses":null,"alternative":null},"vendorSpecific-urn:etsi:mec:capifext:transport-info":{"name":"HTTP REST API","type":"REST_HTTP","protocol":"HTTP","version":"2.0","security":{}}}],"vendorSpecific-urn:etsi:mec:capifext:service-info":{"serializer":"JSON","state":"ACTIVE","scopeOfLocality":"MEC_HOST","consumedLocalOnly":true,"isLocal":true,"category":{"href":"http://mec-platform2.etsi.org:31111/sandbox/v1/statistic/v1/quantity","id":"98a5039d-2b7c-49b1-b3b1-45a6ebad2ea4","name":"Demo","version":"1.0.0"}}}]}'
logger.info('apiId: ' + str(data['serviceAPIDescriptions'][0]['apiId'] + ' matching MEC serInstanceID'))
logger.info('aefId: ' + str(data['serviceAPIDescriptions'][0]['aefProfiles'][0]['aefId'] + ' matching MEC TransportInfo.Id"'))
# Delete the MEC servce
delete_mec_service(mec_service_resource)
# Terminate the MEC application
mec_app_termination(sandbox_name, app_inst_id, sub_id)
logger.debug('Stopped at ' + time.strftime('%Y%m%d-%H%M%S'))
# End of function process_main
if __name__ == '__main__':
process_main()
```
%% Cell type:markdown id: tags:
# Annexes
## Annex A: How to use an existing MEC sandbox instance
This case is used when the MEC Sandbox API is not used. The procedure is the following:
- Log to the MEC Sandbox using a WEB browser
- Select a network scenario
- Create a new application instance
When it is done, the newly created application instance is used by your application when required. This application instance is usually passed to your application in the command line or using a configuration file
%% Cell type:markdown id: tags:
### Bibliography
1. ETSI GS MEC 002 (V2.2.1) (01-2022): "Multi-access Edge Computing (MEC); Phase 2: Use Cases and Requirements".
2. ETSI GS MEC 010-1 (V1.1.1) (10-2017): "Mobile Edge Computing (MEC); Mobile Edge Management; Part 1: System, host and platform management".
3. ETSI GS MEC 010-2 (V2.2.1) (02-2022): "Multi-access Edge Computing (MEC); MEC Management; Part 2: Application lifecycle, rules and requirements management".
4. ETSI GS MEC 011 (V3.2.1) (09-2022): "Multi-access Edge Computing (MEC); Edge Platform Application Enablement".
5. ETSI GS MEC 012 (V2.2.1) (02-2022): "Multi-access Edge Computing (MEC); Radio Network Information API".
6. ETSI GS MEC 013 (V2.2.1) (01-2022): "Multi-access Edge Computing (MEC); Location API".
7. ETSI GS MEC 014 (V2.1.1) (03-2021): "Multi-access Edge Computing (MEC); UE Identity API".
8. ETSI GS MEC 015 (V2.1.1) (06-2020): "Multi-Access Edge Computing (MEC); Traffic Management APIs".
9. ETSI GS MEC 016 (V2.2.1) (04-2020): "Multi-access Edge Computing (MEC); Device application interface".
10. ETSI GS MEC 021 (V2.2.1) (02-2022): "Multi-access Edge Computing (MEC); Application Mobility Service API".
11. ETSI GS MEC 028 (V2.3.1) (07-2022): "Multi-access Edge Computing (MEC); WLAN Access Information API".
12. ETSI GS MEC 029 (V2.2.1) (01-2022): "Multi-access Edge Computing (MEC); Fixed Access Information API".
13. ETSI GS MEC 030 (V3.2.1) (05-2022): "Multi-access Edge Computing (MEC); V2X Information Service API".
14. ETSI GR MEC-DEC 025 (V2.1.1) (06-2019): "Multi-access Edge Computing (MEC); MEC Testing Framework".
15. ETSI GR MEC 001 (V3.1.1) (01-2022): "Multi-access Edge Computing (MEC); Terminology".
16. ETSI GR MEC 003 (V3.1.1): Multi-access Edge Computing (MEC);
17. 3GPP TS 29.222: 3rd Generation Partnership Project; Technical Specification Group Core Network and Terminals; Common API Framework for 3GPP Northbound APIs
Framework and Reference Architecture
18. [The Wiki MEC web site](https://www.etsi.org/technologies/multi-access-edge-computing)
......
examples/demo6/python/notebook/images/capif.png 0 → 100644
View file @ 1e5ccfe0
examples/demo6/python/notebook/images/capif.png

53.3 KiB

go-apps/meep-ams/api/swagger.yaml
View file @ 1e5ccfe0
openapi: 3.0.0
info:
title: AdvantEDGE Application Mobility API
version: '2.2.1'
version: '3.1.1'
description: Application Mobility Service is AdvantEDGE's implementation of [ETSI
MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf)
MEC ISG MEC021 Application Mobility API](https://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/03.01.01_60/gs_mec021v030101p.pdf)
<p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt)
<p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams)
<p>**Type & Usage**<br>Edge Service used by edge applications that want to get
......@@ -16,8 +16,8 @@ info:
name: InterDigital AdvantEDGE Support
email: AdvantEDGE@InterDigital.com
externalDocs:
description: ETSI GS MEC 021 Application Mobility Service API, v2.2.1
url: https://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_mec021v020201p.pdf
description: ETSI GS MEC 021 Application Mobility Service API, v3.1.1
url: https://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/03.01.01_60/gs_mec021v030101p.pdf
servers:
- url: https://localhost/sandboxname/amsi/v1
variables: {}
......@@ -40,30 +40,30 @@ paths:
explode: true
schema:
type: string
- name: all_fields
- name: All_fields
in: query
description: Include all complex attributes in the response.
style: form
explode: true
schema:
type: string
- name: fields
- name: Fields
in: query
description: Complex attributes to be included into the response. See clause 6.18 in ETSI GS MEC 009
style: form
explode: true
schema:
type: string
- name: exclude_fields
- name: Exclude_fields
in: query
description: Complex attributes to be excluded from the response.See clause 6.18 in ETSI GS MEC 009
style: form
explode: true
schema:
type: string
- name: exclude_default
- name: Exclude_default
in: query
description: Indicates to exclude the following complex attributes from the response See clause 6.18 in ETSI GS MEC 011 for details.
description: Indicates to exclude the following complex attributes from the response See clause 6.18 in ETSI GS MEC 009 for details.
style: form
explode: true
schema:
......@@ -133,35 +133,35 @@ paths:
parameters:
- name: filter
in: query
description: Attribute-based filtering parameters according to ETSI GS MEC 011
description: Attribute-based filtering parameters, according to ETSI GS MEC 009, use the format (op,attr,value)
style: form
explode: true
schema:
type: string
- name: all_fields
- name: All_fields
in: query
description: Include all complex attributes in the response.
description: Include all complex attributes in the response. e.g., All_Fields.
style: form
explode: true
schema:
type: string
- name: fields
- name: Fields
in: query
description: Complex attributes to be included into the response. See clause 6.18 in ETSI GS MEC 011
description: Complex attributes to be included in the response (see Clause 6.18 in ETSI GS MEC 009), e.g., att or att/subatt.
style: form
explode: true
schema:
type: string
- name: exclude_fields
- name: Exclude_fields
in: query
description: Complex attributes to be excluded from the response.See clause 6.18 in ETSI GS MEC 011
description: Complex attributes to be excluded in the response (see Clause 6.18 in ETSI GS MEC 009), e.g., att or att/subatt.
style: form
explode: true
schema:
type: string
- name: exclude_default
- name: Exclude_default
in: query
description: Indicates to exclude the following complex attributes from the response See clause 6.18 in ETSI GS MEC 011 for details.
description: Indicates to exclude the following complex attributes from the response See clause 6.18 in ETSI GS MEC 009 for details.
style: form
explode: true
schema:
......
go-apps/meep-ams/server/ams.go
View file @ 1e5ccfe0
......@@ -28,6 +28,7 @@ import (
"net/http"
"net/url"
"os"
"regexp"
"sort"
"strconv"
"strings"
......@@ -148,6 +149,19 @@ func notImplemented(w http.ResponseWriter, r *http.Request) {
w.WriteHeader(http.StatusNotImplemented)
}
type RegisterationInfoList struct {
Registrations []RegistrationInfo
Filters *FilterParameters
}
type FilterParameters struct {
filter string
all_fields string
fields string
exclude_fields string
exclude_default string
}
// Init - App Mobility Service initialization
func Init() (err error) {
......@@ -1205,8 +1219,10 @@ func subscriptionLinkListSubscriptionsGet(w http.ResponseWriter, r *http.Request
u, _ := url.Parse(r.URL.String())
q := u.Query()
validQueryParams := []string{"subscriptionType"}
if !validateQueryParams(q, validQueryParams) {
w.WriteHeader(http.StatusBadRequest)
err := validateQueryParams(q, validQueryParams)
if err != nil {
errHandlerProblemDetails(w, err.Error(), http.StatusBadRequest)
return
}
......@@ -1473,20 +1489,51 @@ func appMobilityServiceByIdDELETE(w http.ResponseWriter, r *http.Request) {
}
func appMobilityServiceGET(w http.ResponseWriter, r *http.Request) {
w.Header().Set("Content-Type", "application/json; charset=UTF-8")
// Validate query parameters
u, _ := url.Parse(r.URL.String())
q := u.Query()
validParams := []string{"filter", "All_fields", "Fields", "Exclude_fields", "Exclude_default"}
err := validateQueryParams(q, validParams)
if err != nil {
print("Query Parameter error")
errHandlerProblemDetails(w, err.Error(), http.StatusBadRequest)
return
}
// Parse query parameters
urlFilter := q.Get("filter")
urlAllFields := q.Get("All_fields")
urlfields := q.Get("Fields")
urlExcludeFields := q.Get("Exclude_fields")
urlExcludeDefault := q.Get("Exclude_default")
regInfoList := &RegisterationInfoList{
Filters: &FilterParameters{
filter: urlFilter,
all_fields: urlAllFields,
fields: urlfields,
exclude_fields: urlExcludeFields,
exclude_default: urlExcludeDefault,
},
Registrations: make([]RegistrationInfo, 0),
}
// Get all AMS Registration Info
regInfoList := make([]RegistrationInfo, 0)
//regInfoList := make([]RegistrationInfo, 0)
key := baseKey + "svc:*:info"
err := rc.ForEachJSONEntry(key, populateRegInfoList, &regInfoList)
err = rc.ForEachJSONEntry(key, populateRegInfoList, regInfoList)
if err != nil {
log.Error(err.Error())
errHandlerProblemDetails(w, err.Error(), http.StatusInternalServerError)
return
}
// Send response
jsonResponse, err := json.Marshal(regInfoList)
// Prepare & send response
jsonResponse, err := json.Marshal(regInfoList.Registrations)
if err != nil {
log.Error(err.Error())
errHandlerProblemDetails(w, err.Error(), http.StatusInternalServerError)
......@@ -1498,9 +1545,9 @@ func appMobilityServiceGET(w http.ResponseWriter, r *http.Request) {
}
func populateRegInfoList(key string, jsonEntry string, response interface{}) error {
regInfoList := response.(*[]RegistrationInfo)
if regInfoList == nil {
return errors.New("Response not defined")
data := response.(*RegisterationInfoList)
if data == nil {
return errors.New("response not defined")
}
// Retrieve registration info from DB
......@@ -1509,7 +1556,202 @@ func populateRegInfoList(key string, jsonEntry string, response interface{}) err
if err != nil {
return err
}
*regInfoList = append(*regInfoList, regInfo)
// Filter services
if data.Filters != nil {
// Filter Paramter
if data.Filters.filter != "" {
filterField := data.Filters.filter
// Split filterField into operator, attribute, and value
operator, attribute, value, _ := parseFilter(filterField)
// Apply filters based on attribute
switch attribute {
case "appMobilityServiceId":
if !applyStringFilter(operator, regInfo.AppMobilityServiceId, value) {
return nil
}
case "serviceConsumerId/appInstanceId":
if !applyStringFilter(operator, regInfo.ServiceConsumerId.AppInstanceId, value) {
return nil
}
case "serviceConsumerId/mepId":
if !applyStringFilter(operator, regInfo.ServiceConsumerId.MepId, value) {
return nil
}
case "deviceInformation/associateId":
matched := false
for _, deviceInfo := range regInfo.DeviceInformation {
if applyStringFilter(operator, deviceInfo.AssociateId.Value, value) {
matched = true
break
}
}
if !matched {
return nil
}
case "deviceInformation/appMobilityServiceLevel":
matched := false
for _, deviceInfo := range regInfo.DeviceInformation {
if applyStringFilter(operator, string(*deviceInfo.AppMobilityServiceLevel), value) {
matched = true
break
}
}
if !matched {
return nil
}
case "deviceInformation/contextTransferState":
matched := false
for _, deviceInfo := range regInfo.DeviceInformation {
if applyEnumFilter(operator, string(*deviceInfo.ContextTransferState), value) {
matched = true
break
}
}
if !matched {
return nil
}
case "expiryTime":
expiryTime, err := strconv.ParseUint(value, 10, 32)
if err != nil {
return nil
}
if !applyNumericFilter(operator, uint32(regInfo.ExpiryTime), uint32(expiryTime)) {
return nil
}
default:
return nil
}
}
// Handle Fields Parameter (Include ALL fields)
if data.Filters.all_fields != "" && data.Filters.all_fields != "All_fields" {
return nil
}
// Handle Fields Parameter
if data.Filters.fields != "" {
fields := strings.Split(data.Filters.fields, ",")
filteredRegInfo := RegistrationInfo{}
for _, field := range fields {
switch field {
case "appMobilityServiceId":
filteredRegInfo.AppMobilityServiceId = regInfo.AppMobilityServiceId
case "serviceConsumerId/appInstanceId":
// if filteredRegInfo.ServiceConsumerId == nil {
// filteredRegInfo.ServiceConsumerId = &RegistrationInfoServiceConsumerId{}
// }
if regInfo.ServiceConsumerId.AppInstanceId != "" {
filteredRegInfo.ServiceConsumerId.AppInstanceId = regInfo.ServiceConsumerId.AppInstanceId
}
case "serviceConsumerId/mepId":
// if filteredRegInfo.ServiceConsumerId == nil {
// filteredRegInfo.ServiceConsumerId = &RegistrationInfoServiceConsumerId{}
// }
if regInfo.ServiceConsumerId.MepId != "" {
filteredRegInfo.ServiceConsumerId.MepId = regInfo.ServiceConsumerId.MepId
}
case "deviceInformation/associateId":
for _, deviceInfo := range regInfo.DeviceInformation {
if deviceInfo.AssociateId.Value != "" {
filteredDeviceInfo := RegistrationInfoDeviceInformation{
AssociateId: deviceInfo.AssociateId,
}
filteredRegInfo.DeviceInformation = append(filteredRegInfo.DeviceInformation, filteredDeviceInfo)
}
}
case "deviceInformation/appMobilityServiceLevel":
for _, deviceInfo := range regInfo.DeviceInformation {
if *deviceInfo.AppMobilityServiceLevel != "" {
filteredDeviceInfo := RegistrationInfoDeviceInformation{
AppMobilityServiceLevel: deviceInfo.AppMobilityServiceLevel,
}
filteredRegInfo.DeviceInformation = append(filteredRegInfo.DeviceInformation, filteredDeviceInfo)
}
}
case "deviceInformation/contextTransferState":
for _, deviceInfo := range regInfo.DeviceInformation {
if *deviceInfo.ContextTransferState != "" {
filteredDeviceInfo := RegistrationInfoDeviceInformation{
ContextTransferState: deviceInfo.ContextTransferState,
}
filteredRegInfo.DeviceInformation = append(filteredRegInfo.DeviceInformation, filteredDeviceInfo)
}
}
case "expiryTime":
//Logic
if string(regInfo.ExpiryTime) != "" {
filteredRegInfo.ExpiryTime = regInfo.ExpiryTime
}
}
// Replace regInfo with the filtered version
}
regInfo = filteredRegInfo
}
// Handle Exclude Fields Parameter (Exclude specified fields)
if data.Filters.exclude_fields != "" {
excludeFields := strings.Split(data.Filters.exclude_fields, ",")
filteredRegInfo := regInfo
// Exclude the listed fields
for _, field := range excludeFields {
switch field {
case "appMobilityServiceId":
filteredRegInfo.AppMobilityServiceId = "" // Exclude this field
case "serviceConsumerId/appInstanceId":
if filteredRegInfo.ServiceConsumerId != nil {
filteredRegInfo.ServiceConsumerId.AppInstanceId = "" // Exclude this field
}
case "serviceConsumerId/mepId":
if filteredRegInfo.ServiceConsumerId != nil {
filteredRegInfo.ServiceConsumerId.MepId = "" // Exclude this field
}
case "deviceInformation/associateId":
for i := range filteredRegInfo.DeviceInformation {
filteredRegInfo.DeviceInformation[i].AssociateId = nil // Exclude this field
}
case "deviceInformation/appMobilityServiceLevel":
for i := range filteredRegInfo.DeviceInformation {
filteredRegInfo.DeviceInformation[i].AppMobilityServiceLevel = nil // Exclude this field
}
case "deviceInformation/contextTransferState":
for i := range filteredRegInfo.DeviceInformation {
filteredRegInfo.DeviceInformation[i].ContextTransferState = nil // Exclude this field
}
case "expiryTime":
filteredRegInfo.ExpiryTime = 0 // Exclude this field
}
}
// Replace regInfo with the filtered version based on exclude_fields parameter
regInfo = filteredRegInfo
}
// Handle Exclude Fields default Parameter (Exclude specified fields)
}
// Returning Data
data.Registrations = append(data.Registrations, regInfo)
return nil
}
......@@ -2324,21 +2566,22 @@ func delTrackedDevInfo(svcId string, address string) error {
return nil
}
func validateQueryParams(params url.Values, validParamList []string) bool {
func validateQueryParams(params url.Values, validParams []string) error {
for param := range params {
found := false
for _, validParam := range validParamList {
for _, validParam := range validParams {
if param == validParam {
found = true
break
}
}
if !found {
log.Error("Invalid query param: ", param)
return false
err := errors.New("Invalid query param: " + param)
log.Error(err.Error())
return err
}
}
return true
return nil
}
func validateQueryParamValue(val string, validValues []string) bool {
......@@ -2370,3 +2613,92 @@ func errHandlerProblemDetails(w http.ResponseWriter, error string, code int) {
w.WriteHeader(code)
fmt.Fprint(w, jsonResponse)
}
func parseFilter(filterField string) (string, string, string, error) {
// Regular expression to match the filter format
re := regexp.MustCompile(`^(eq|neq|gt|lt|gte|lte|in|nin|cont|ncont),([a-zA-Z0-9/]+),([^,]+)(?:,([^,]+))?$`)
// Trim any surrounding parentheses
filterField = strings.Trim(filterField, "()")
// Match the filterField against the regular expression
matches := re.FindStringSubmatch(filterField)
if len(matches) < 3 {
return "", "", "", nil
}
// Extract the operator, attribute, and value(s)
operator := matches[1]
attribute := matches[2]
value := matches[3]
// If there's a second value (for operators like "in" or "nin"), handle it
if len(matches) > 4 && matches[4] != "" {
value += "," + matches[4]
}
return operator, attribute, value, nil
}
// Helper functions for applying filters
func applyStringFilter(operator, fieldValue, filterValue string) bool {
switch operator {
case "eq":
return fieldValue == filterValue
case "neq":
return fieldValue != filterValue
case "cont":
return strings.Contains(fieldValue, filterValue)
case "ncont":
return !strings.Contains(fieldValue, filterValue)
case "in":
values := strings.Split(filterValue, ",")
for _, v := range values {
if fieldValue == v {
return true
}
}
return false
case "nin":
values := strings.Split(filterValue, ",")
for _, v := range values {
if fieldValue == v {
return false
}
}
return true
case "gt":
return fieldValue > filterValue
case "gte":
return fieldValue >= filterValue
case "lt":
return fieldValue < filterValue
case "lte":
return fieldValue <= filterValue
default:
return false
}
}
func applyEnumFilter(operator, fieldValue, filterValue string) bool {
return applyStringFilter(operator, fieldValue, filterValue)
}
func applyNumericFilter(operator string, fieldValue, filterValue uint32) bool {
switch operator {
// case "eq":
// return fieldValue == filterValue
// case "neq":
// return fieldValue != filterValue
case "gt":
return fieldValue > filterValue
case "gte":
return fieldValue >= filterValue
case "lt":
return fieldValue < filterValue
case "lte":
return fieldValue <= filterValue
default:
return false
}
}
go-apps/meep-ams/server/api_amsi.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/api_unsupported.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/backup.go 0 → 100644
View file @ 1e5ccfe0
package server
go-apps/meep-ams/server/logger.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_info_notification.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_info_notification_adjacent_app_info.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_info_subscription.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_info_subscription_filter_criteria.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_info_subscription_links.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_adjacent_app_instance_info.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_app_mobility_service_level.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_app_termination_notification.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_app_termination_notification__links.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
go-apps/meep-ams/server/model_associate_id.go
View file @ 1e5ccfe0
......@@ -17,7 +17,7 @@
*
* Application Mobility Service is AdvantEDGE's implementation of [ETSI MEC ISG MEC021 Application Mobility API](http://www.etsi.org/deliver/etsi_gs/MEC/001_099/021/02.02.01_60/gs_MEC021v020201p.pdf) <p>[Copyright (c) ETSI 2017](https://forge.etsi.org/etsi-forge-copyright-notice.txt) <p>**Micro-service**<br>[meep-ams](https://github.com/InterDigitalInc/AdvantEDGE/tree/master/go-apps/meep-ams) <p>**Type & Usage**<br>Edge Service used by edge applications that want to get information about application mobility in the network <p>**Note**<br>AdvantEDGE supports a selected subset of Application Mobility API endpoints (see below).
*
* API version: 2.2.1
* API version: 3.1.1
* Contact: AdvantEDGE@InterDigital.com
* Generated by: Swagger Codegen (https://github.com/swagger-api/swagger-codegen.git)
*/
......
